Specifications
1,Famous Brand (OEM Allowed)2,Certificates:CE,UL,RoHS,CCC
3,German technology
4,Ex stock
Parameters:
Item No. |
Motor(IP55) |
Service factor |
Oper.liquid qty. |
Sound |
Weight |
Metrial |
|||
Frequency |
Output |
Rated |
|||||||
Voltage |
Current |
||||||||
2LV7 070-7AH06 |
50HZ |
2.4kw |
200-240/345-415V |
16.6/9.6A |
1.75 |
0.28m3/h |
66dB |
35 |
A |
60HZ |
3.5kw |
200-275/ 345-480V |
1.29 |
0.34m3/h |
72dB |
||||
Performance:
Size:
How it works:
The impeller rotates friction free withine the pump casing.A rotating liquid ring seals the impeller on the front and seals its blades against one another .In order to keep the liquid ring stable,liquid is also permanently sucked into the compression chamber and is output together with the conveyed gas,The excentrical arrangement of the impeller within the casing creates variable compression chambers between the impeller blades during rotation,which causes the conveyed gas to be compressed within a full revolution.
Liquid ring pumps and compressors utilize rotating positive displacement technology and are typically used in liquid ring vacuum pump applications.but can also be used as a gas,or liquid ring compressor.These sturdy pumps are built for heavy duty,wet and humid applications where most other pumps' performance will drop due to abrasion and lime scale from the process.The larger liquid ring pumps are often part of engineered systems designed to meet even the highest demands.
Extreme conditions, which prevail in humid and wet processes, lead to lime scale or abrasion, and hence to a considerable reduction in the performance of the pump. Elmo Rietschle liquid ring pumps, however, meet these challenges.
The use of high-quality materials such as stainless steel and ceramics ensure utmost reliability and constant operating characteristics – for years to come.
Advantages at a glance
· Constant operating characteristics by ceramic coating
· Maximum abrasion resistance
· Excellent corrosion resistance
· No deposits and lime scale
Applicantion:
1,Asphalt-thickening machines(steamrollers)
2,Corrosion protection for water pipes
3,Drying systems
4,Dust extraction in the mining industry
5,Extracting oil residues
6,Exhausts in sewage treatment plants
7,Lifting and handling
8,Material damping in the textile industry
9,Steam turbines and motors
10,Systems for cleaning and removing fat from particies in hydrocarbons
11,Systems to lower the water table
Certification:
Production Line:
