NT30 ER collet chuck
1)Material:high quality alloy steel
2)packing:by plastic box
3)Sizes: NT30xER20-50,NT30XER25-50 etc,whose details is given below:
| modle no. | 7:24 No. | d | D | L1 |
| NT30xER11-50 | 30 | 1-7 | 19 | 50 |
| NT30xER16-63 | 30 | 1-10 | 28 | 63 |
| NT30xER20-63 | 30 | 1-13 | 34 | 63 |
| NT30xER25-63 | 30 | 1-16 | 42 | 63 |
| NT30xER32-63 | 30 | 2-20 | 50 | 63 |
| NT30xER40-75 | 30 | 3-26 | 63 | 75 |
| NT40xER16-63 | 40 | 1-10 | 28 | 63 |
| NT40xER20-60 | 40 | 1-13 | 34 | 60 |
| NT40xER25-60 | 40 | 1-16 | 42 | 60 |
| NT40xER32-70 | 40 | 2-20 | 50 | 70 |
| NT40xER40-60 | 40 | 3-26 | 63 | 60 |
| NT40xER50-100 | 40 | 6-34 | 78 | 100 |
| NT50xER16-63 | 50 | 1-10 | 28 | 63 |
| NT50xER20-60 | 50 | 1-13 | 34 | 60 |
| NT50xER25-60 | 50 | 1-16 | 42 | 60 |
| NT50xER32-70 | 50 | 2-20 | 50 | 70 |
| NT50xER40-70 | 50 | 3-26 | 63 | 70 |
| NT50xER50-90 | 50 | 6-34 | 78 | 90 |
packaging way:Inner packing is by plastic box.The outer packing is by cartons.Pallet is available upon the customer's request.
Quality: Each product are inspected durding the production.And then rendomly are selceted for inspection by quality-person.We have exported our goods to around the world and get good feebacks.
Shipment way: We can send the goods by sea,air or couirer(DHL,TNT,Fedex etc) according to the customer's requirement.
Our Services and reputation: we have been the supplier at Alibaba for 9(nine) years.
We always keep our promise and are responsible for the problems if occured after sales.Pls be assured.
