HY-1700NC High efficiency deep hole drlling machine
Introduction:
According to the home and over seas advanced machine tool manufacturing technology,our engineer independently developed the High Efficiency Deep Hole Drilling Machine which is deep blind hole processing machine.
The machine is mainly apply to deep blind blind hole processing,for example,machinery,instrument,electrical equipment and mold making.Even apply to high accuracy requirement deep blind hole blind hole processing of protective casing,In single-shaft and double-shaft two types.
There are HY-500NC,HY-1000NC,HY-1500NC,HY-1700NC,HY-2000NC and many types can choose.
Features
1.Using Numerically controlling drive,high degree of automation,easy to handle,high precision and efficiency.Machie precision can be equal to import equipment.
2.HY series gun-drill machine use special filter colling ststem.Under the circumstances of not obviously increase space,it greatly improved working life of cooling liquid and reduced the Comprehensive processing cost.
3.Wide processing range,processing depth can reach 500mm-2000mm,hole diameter φ 2mm-φ12mm.
4.Comparing to overseas,the price of this machine 1/10 of similar type.The energy consumption is 1/3 of similar type.
Technical reference
| Product name | HY-1700NC High efficiency deep hole drlling machine |
| Number of drilling spindle/axle | 1 Axle |
| machinetool longest workpiece | 1700mm |
| Max outer diameter of workpiece | OD 38mm |
| Max outer diameter of chuck | OD 50mm |
| Spindle speed | 97R/min |
| Gun-drill revolving speed | 500-4000R/min |
| Cutting speed | 0-50mm/min |
| Drill diameter | 3-12mm |
| Drill depth | 1700mm |
| Main motor power | 0.75KW |
| Gun-drill motor power | 2.2KW |
| Cutting oil pump power | 3/4KW |
| Feed motor torque | 24 N.m |
| Cutting oil pump pressure | 7Mpa |
| Oil pump capacity | 20/40 L/min |
| Cutting capacity of tank | 800L |
| Nc System | Nanjing Xingqiang |
Product show
Order Detail
1. Model Number
2. Quanity
,South East Asia, Middle East,North America, Europe and so on.
We usually accept T/T(with 30% deposit, the balance before shipment);
L/C at sight, please send email to negotiate payment term if you can not accept T/T or L/C
wooden case or specified package
How to oder products?
---Send inquiry to us or contact with us via email,skype or trademanager
---Confirming the model, specification, price, qty, delivery time and payment method
---provide samples if any necessary
---Sending invoice to customer
---Customer makes payment and send us receipt
---Arranging production
---Sending products picture to customer after the production is ready
---Shipping products to customer and provide all the customs clearance documents
Huadong Instrument and Meter Factory Yueqing was estabilshed in 1986.After nearly 30 years of accumulation and precipitation.Through the concert dfforts of all staff,our factory has become a national industrial fammous enterprise,with annual output of 150 pieces(sets)of various industrues production capacity of equipment,production of "HY" series gun drilling(hole) machine,polishing machine,core-out machine,straighten machine,locking machine and multifunctional welding machine,fill a number of industry field blank,which greatly improves the production efficiency.
Our Advantages
Competitive price
We are manufacture, so you get directly from factory that is actively controlling for mutual benefit.
Quality Control System
With experienced engineers and QA workers, each manufacturing process is checked and audited strictly. Incoming quality control conducts inspections and handle quality issues before the assembly process starts. Our In-Process Quality Control process governs our quality systems during the assembly process in order to detect and handle any problems that may arise during assembly. Outgoing quality assurance is the last process before products ship to customers, and hence is very important in ensuring our shipment is defect-free. Numerous redundancies with IQC and IPQC exist here to ensure the validity of previous processes.
OEM services
The factory can produce the product according to the client's engineering drawings. Client's mark can be labeled on packaging for OEM products.
Short lead time and prompt shipment
