Home > Products > Manufacture equipment > HY-500NC High efficiency deep hole drlling machine
HY-500NC High efficiency deep hole drlling machine
- 5 Piece / Pieces per Month
- Shanghai/Ningbo
- T/T Credit Card
- Multifunction high frequency direct pulse argon arc welding machine
- Multifunction high frequency direct current argon arc welding machine
- HUAI KUI OEM Armored cable straightening machine HYJZJ-8-3
- HUA KUI Armored cable straightening machine armored thermocouple unrestricted machine HYPGJ-01C
- Metal pipe surface polishing machine tube surface polishing machine
- Huakui high quality Multifuction High Frequency Direct Current/Pulse Argon Welding machines pot welding machine
Product Details
Place of Origin: | Zhejiang, China | Brand Name: | HUAKUI | Model Number: | HY-500NC |
Condition: | New | After-sales Service Provided: | No overseas service provided |
Packaging Details
wooden case doe machine or other special package you need
Product Description
HY-500NC High efficiency deep hole drlling machine
Introduction:
According to the home and over seas advanced machine tool manufacturing technology,our engineer independently developed the High Efficiency Deep Hole Drilling Machine which is deep blind hole processing machine.
The machine is mainly apply to deep blind blind hole processing,for example,machinery,instrument,electrical equipment and mold making.Even apply to high accuracy requirement deep blind hole blind hole processing of protective casing,In single-shaft and double-shaft two types.
There are HY-500NC,HY-1000NC,HY-1500NC,HY-1700NC,HY-2000NC and many types can choose.
Features
1.Using Numerically controlling drive,high degree of automation,easy to handle,high precision and efficiency.Machie precision can be equal to import equipment.
2.HY series gun-drill machine use special filter colling ststem.Under the circumstances of not obviously increase space,it greatly improved working life of cooling liquid and reduced the Comprehensive processing cost.
3.Wide processing range,processing depth can reach 500mm-2000mm,hole diameter φ 2mm-φ12mm.
4.Comparing to overseas,the price of this machine 1/10 of similar type.The energy consumption is 1/3 of similar type.
Technical reference
Product name | HY-500NC High efficiency deep hole drlling machine |
Number of drilling spindle/axle | 1/2 Axle |
machinetool longest workpiece | 500mm |
Max outer diameter of workpiece | OD 38mm |
Max outer diameter of chuck | OD 50mm |
Spindle speed | 97R/min |
Gun-drill revolving speed | 500-4000R/min |
Cutting speed | 0-60mm/min |
Drill diameter | 3-12mm |
Drill depth | 500mm |
Main motor power | 0.75KW |
Gun-drill motor power | 2.2KW |
Cutting oil pump power | 3/4KW |
Feed motor torque | 16 N.m |
Cutting oil pump pressure | 7Mpa |
Oil pump capacity | 20/40 L/min |
Cutting capacity of tank | 600L |
Nc System | Nanjing Xingqiang |
Product show
Order Detail
1. Model Number
2. Quanity
,South East Asia, Middle East,North America, Europe and so on.
We usually accept T/T(with 30% deposit, the balance before shipment);
L/C at sight, please send email to negotiate payment term if you can not accept T/T or L/C
wooden case or specified package
How to oder products?
---Send inquiry to us or contact with us via email,skype or trademanager
---Confirming the model, specification, price, qty, delivery time and payment method
---Sending invoice to customer
---Customer makes payment and send us receipt
---Arranging production
---Sending products picture to customer after the production is ready
---Shipping products to customer
Huadong Instrument and Meter Factory Yueqing was estabilshed in 1986.After nearly 30 years of accumulation and precipitation.Through the concert dfforts of all staff,our factory has become a national industrial fammous enterprise,with annual output of 150 pieces(sets)of various industrues production capacity of equipment,production of "HY" series gun drilling(hole) machine,polishing machine,core-out machine,straighten machine,locking machine and multifunctional welding machine,fill a number of industry field blank,which greatly improves the production efficiency.
Our Advantages
Competitive price
We are manufacture, so you get directly from factory that is actively controlling for mutual benefit.
Quality Control System
With experienced engineers and QA workers, each manufacturing process is checked and audited strictly. Incoming quality control conducts inspections and handle quality issues before the assembly process starts. Our In-Process Quality Control process governs our quality systems during the assembly process in order to detect and handle any problems that may arise during assembly. Outgoing quality assurance is the last process before products ship to customers, and hence is very important in ensuring our shipment is defect-free. Numerous redundancies with IQC and IPQC exist here to ensure the validity of previous processes.
OEM services
The factory can produce the product according to the client's engineering drawings. Client's mark can be labeled on packaging for OEM products.
Short lead time and prompt shipment
Company Profile
Huadong Instrument and Meter Factory Yueqing was established by Mr. Xinghua Wu in 1986. Through two decades of trials and tribulations, we have developed into a flourishing enterprise with registered capital of USD1, 230,000, Our products range from thermocouples, RTDs, and electric heaters and parts ,processing machines.
During the few years, we have obtained the certificate for the Class-A Suppliers of China Oil and Gas Group, and the certificate for Logistic Supplies for China Petrochemical Group, as well as the certificate awarded by the National Monitoring Bureau for Meter Ignition-Proof Criteria. Moreover, we are honored to have passed the evaluation of ISO9001.
We are now progressing on the basis of the creations and innovations of a dozen of experienced and skilled experts and technicians to develop new products and create new wonders.
Our products are from thermocouples and RTDs to integrated thermal transmitters and pressure transmitters, from armored thermal elements for thermocouples and RTDs to armored heating cables (with teflon, PVC or Cu-lined protecting sheath) for thermocouples, and from electric heaters to spare parts for thermocouples and RTDs.
All of our products are produced strictly according to IEC and our own standards, which enables us to take the lead in the domestic market. It is our greatest honor that our products have been selected by domestic users as the substitutes for their foreign counterparts, which indicates that we possess the superiority of price and quality over our competitors.
Deeply rooted in the domestic market, we are now well prepared to the access of the international market. Our export amount has been increasing steadily on the yearly basis since 2000. Now our overseas business which totals 10~15% of our overall sales amount covers a large scale of America, Canada, South Africa, Germany, the Middle East and Asian and Pacific regions. We are confident that we can join hands with our customers for a bright future ahead.
