Cheap Fan Filter Unit
FFU, short for Fan Filter Unit, a leading-edge fan filter unit (FFU) designed to provide filtered laminar airflow over a specific area, which draws in contaminated air from the top of the module, and exhausts filtered clean air vertically in a unidirectional(laminar) air stream at its base, is a self-contained fan and filter module for cleanroom applications.
FFU provides clean air as well as particle controlling. These series, the general dimensions of which are 2×4 and 4×4 inches, are often installed on the ceiling of clean rooms.
Application: Used in clean rooms ranging from class 100,000 to 10, they can come into being ultra-clean assembly line, clean work office, clean booth, clean closet and etc...
- Nice appearance , human centered design---Adding stainless handle, easy installation and delivery, and perpendicular design.
- High performance and low noise fans---Adopting Energy-saving Multi-blade turbine fan, lower noise, Pressure spreads evenly, stable air velocity, low consumption, low running cost, service life can reach to longer than 80 thousand hours.
- Light, thin shape---Without filter net, thickness of shape is 23cm, 25KG weight, application in low ceiling are also available.
- Flexible, diversified design---Except for standard items, custom made FFU is available, such changings as filter nets, the materials of shell and etc...
- Concerning, convenient design---Pedals are designed in the body, which makes it convenient to install and repair.
- Premium Current-averaging design of the inside---Ensures deviation of the blowing side lower than ±10%.
Model |
JJ-4-2 |
JJ-4-4 |
JJ-2-2 |
|||
Dimension |
mm |
1175*575*230 |
1175*1175*230 |
575*575*230 |
||
Air flow |
M3/h |
1400 |
2350 |
800 |
||
External static pressure |
Pa |
98 |
98 |
98 |
||
|
Main body |
- |
Standard |
Cold rolled steel plate with powder coated |
|||
|
option |
Stainless steel(SUS304) Galvanized steel |
|||||
Power supply |
Standard |
V/Hz |
220V 50/60Hz |
|||
Option |
V/Hz |
Pls contact us if you have any other requirement about the power. |
||||
|
Filter |
Efficiency |
- |
HEPA Over 99.99% @ 0.3um |
|||
- |
ULPA Over 99.9995% @ 0.1um |
|||||
Frame |
- |
Aluminum |
||||
Power dissipation |
W |
120 |
245 |
90 |
||
Weight |
Kg |
25 |
45 |
15 |
||
Shock |
m/s2 |
≤0.4 |
≤1.1 |
≤0.4 |
||
Noise |
Db(a) |
≤55 |
≤55 |
≤55 |
||
Option |
- |
Differential draft gauge; Remote control; Duct flange for suction air; Pre-filter |
||||
