144 Core Dome Fiber Optical Splice Closure Manufacturer
- 10000 Piece / Pieces per Month
- Shanghai/Shenzhen
- T/T Credit Card PayPal
- ZTE 5928E, RS-5928E, RS-59EC-PWR-AC10, RS-59EC-PWR-DC10, 24 GE RJ45 + 1 expansion card ZTE ZXR10 5928E 5952E 5916E RS-5916E RS-
- ZTE 2952E, RS-2952E-AC, RS-2952E-DC, 48 FE RJ45 4 GE SFP ZTE ZXR10 2952E 2928E 2918E 2910E
- ZTE 3950-28TM, RS-3950-28TM-AC, 24 FE RJ45 + 2 GE SFP + 1 expansion card slot ZTE ZXR10 3950
- ZTE 2950-18TC, RS-2950-18TC-AC, 16 FE RJ45 + 2 GE Combo ZTE ZXR10 2950
- ZTE S2XF48A, 48-port 10GE SFP+ optical interface ZTE ZXR10 8902E 8905E 8908E 8912E RS-8902E RS-8905E RS-8908E RS-8912E
- ZTE 5250-28PM-H, RS-5250-28PM-H, 20 GE RJ45 (POE/POE+) + 4 GE Combo ports + 1 expansion card ZTE ZXR10 5250
Product Details
Place of Origin: | Sichuan, China | Brand Name: | Yuantong | Model Number: | Splice Closure |
Product Description
144 Core Dome Fiber Optical Splice Closure Manufacturer
Product Description
Fiber Optic Splice Closure is a fiber management product typically used with outdoor fiber optical cables. It
provides space and protection for the fiber optic cable splicing and joint. Fiber splice closure is used for aerial,
strand-mount FTTH locations where drop cables are spliced to distribution cables. With different kinds of ports
types, the products can fit different fiber optic core numbers. It is suitable for protecting optical fiber splices in
straight through and branching applications, and can be used in aerial, duct and direct buried fiber optic cable
projects. We can supply Dome type and In-line type. The max capacity includes 12 core, 24 core, 48 core, 72
core, 96 core and 144 core.
Application
Aerial-hanging
Wall-mounting
Underground
Direct-bury
Technical Paremeters
Working temperature: -5℃ to +40℃
Relative humidity: ≤85% (at +30℃)
Atmospheric pressure: 70Kpa~106Kpa
Specification
Item No. | In and out No. | Max Capacity (Fibers) | Dimension (mm) | Cable diameter | Gross weight (kg) | Sealing structure | Normal configure |
1 | 1-1 | 48 (4x12) | 500x190x90 | Φ7-18 | 3 | Seal tape | 12 |
2 | 1-1 | 60 (5x12) | 502x180x116 | Φ7-18 | 3 | Seal tape or silicon rubber | 12 |
3 | 2-2 | 60 (5x12) | 460x180x108 | Φ7-18 | 3 | Seal tape or silicon rubber | 24 |
4 | 2-2 | 60 (5x12) | 492x180x104 | Φ7-25 | 3 | Seal tape | 24 |
5 | 2-2 | 60 (5x12) | 492x202x104 | Φ7-25 | 3 | Seal tape | 24 |
6 | 4-4 | 96 (8x12) | 492x202x175 | Φ7-25 | 5 | Seal tape | 24 |
7 | 2-2 | 96 (8x12) 120 (5x24) | 599x195x136 | Φ7-25 | 4 | Seal tape or silicon rubber | 24 |
8 | 4-4 | 144 (12x12) 216 (9x24) | 590x195x188 | Φ7-25 | 8 | Seal tape or silicon rubber | 48 |
9 | 6-6 | 72 (6x12) | 490x200x140 | Φ7-25 | 5 | Seal tape | 24 |
10 | 3-3 | 216 (9x24) | 660x260x250 | Φ7-25 | 7 | Seal tape | 36 |
Features
1. Two way cable entries and exists design
2. Can be reopened and re-used
3. Can be fixed by metal work
4. Clear optical fiber cable
5. Closure body is made by Super ABS material, and the bolt is made in stainless steel
6. Great corrosion resistance
7. Suitable for any 144 cores
Certification
Why Choose us?
Firstly, we are manufacturer for the truth, we can control the quality, delivery time, cost of raw material, in this
way we can provide you with high-end products, competitive price and superb service.
Secondly, we have a very professional sales team, who are very familiar with all kinds of overseas trading terms and custom clearance documents in this way we will make your import process very smoothly and pleasantly.
Thirdly, your every inquiry will be took seriously and replied immediately within 24 hours, if the inquiry is complicated will reply u the second day.
Last, but not the least, we have gained Alibaba trade assurance so there’s no worry about our quality.
Payment:
Massive order: T/T, T/T&LC, are all acceptable.
Small order: T/T, Credit- card, west-union are acceptable.
Shipping & Delivery:
Delivery after balance money received, massive quantity by sea while small patch by air.
Warranty:
All products have been tested before delivery.
All products have 1 years after-sale service. If there is no man-made problem, we will replace or repair for you
freely. Even after one year If any problem happened, our team will do our best to help you figure it out, so no worries.
Company Information
Sichuan Yuantong Communication Co.,Ltd was established in 2010, which covers an area of 4000 square
meters in the land of Abudance---Chengdu, Sichuan with US$500 million of regstered capital.
Our company is a high-tech companty putting R&D,production and sales into integrated for the fiber optic
cables and related accessories that are widely used in communication, electric power and other industries.
Yuantong owns a team with professional and technical skill, and has a great deal of experience in production
and sales. “Quality First” is the guideline of us.
Yuantong already has a significant partnership with China Telecom, China Mobile and China Unicom. Also we build good relationship with the customers from South America, Middle East and Southeast Asia,
praised by the majority of the users all around the world.
Our Services
1.Order Information:
Trade term: EXW/FOB
Delivery Time: 3-5 working days time.15-25 working days mass order.
2.Trade Terms:
Payment term: T/T 50% Deposit after order confirmed, later delivery pay the 50% (remaining balance) after goods ready before shipping.
Sample: Be ready in 3~10 days once payment received.
3.Our services:
For all your inqires about our product, we will reply to you within in 24 hrs.
We offer OEM and ODM services and we can print your logo in our products.
Contact Us
- Sichuan Yuantong Communication Co., Ltd.
- Contact nameDavid Wan
- Phone86-028-85050248
- Address#14 Nanshou St, Shuangliu County Chengdu,Sichuan
