Our company is a real professional exporter and we specialize in numerical control machine.
Hydraulic shearing machine/cutting machine
1. CE, ISO, SGS Certification
2. BOSCH Hydraulic system
3. High performance
4. High quality with good price
DESCRIPTIONS about CNC hydraulic cutting machine
|
1. The machine employs hydraulically driven swing beam, the steel plate welded structure, and accumulator based pullback cylinder with steady and reliable operation. |
|
2. Stepless control for the stroke; The gap between up blade and down blade is manually adjusted by handle for high uniformity; Protection fence and the electric interlock to ensure the operation safety. |
|
3. The closed loop control system that consists of CNC system and position coder features fast response speed, high precision, and exceptional stability and can ensure the accuracy of displacement of background. Moreover, CNC system has the accessory functions of compensation and automatic check. |
ITEMS |
PARAMETER |
UNIT |
Model |
QC12K-6X2500 |
set |
Cutting Thickness |
6 |
mm |
Cutting Width |
2500 |
mm |
Cutting Angle |
1°30′ |
0 |
Backgauge Range |
20-600 |
mm |
Stroke Number |
≥12 |
times/min |
Main Motor |
7.5 |
kw |
Weight |
4800 |
kg |
Overall Dimension |
3150X1700X1650 |
LXWXH in mm |
Electric control system of CNC hydraulic cutting machine
1.The mainframe is fitted with numeric-control system special for cutting machine |
2.The position of rear stopper is displayed in a real-time manner. |
|
3.Multistep programming function is available the rear stopper is able for automatic operation and continuous positioning,to achieve an automatic adjustment for position of rear stopper. |
4.It provided with counting function for shearing,to display the shearing number in a real-time manner,able for power-failure memory of position of rear stopper,procedures,and parameters. |
|
5.Imported ball bearing lead screw and linear guide rail are used to ensure the positioning precision of machine is higher. |
Cutting machine controller: E200s
E200s features
1. Backgauge control. |
2. BUS mode control servo system. |
3. Stroke length limitation. |
4. Double programmable digital output. |
5. Program memory of up to 40 programs up to 25 |
6. One side positioning. |
7. Retract function. |
8. Mm/Inch. |
9. Chinese/English. |
Cutting machine controller: DAC360
DAC360 features
1. Panel based housing |
2. Bright LCD screen |
3. Background control |
4. Retract function |
5. Cutting angle control |
6. Cutting gap control |
7. Stroke length limitation |
8. Manual movement of axes |
9. Force control |
Cutting machine controller: DAC310
DAC310 features
1. Background control |
2. Bright LCD display, 275x 48 pixels |
3. Gap or Angle control |
4. Stroke length limitation |
5. Actual and programmable position visualisation |
6. Stock counter |
7. Up to 100 working steps programmable |
8. Panel based housing |
9. Servo, frequency inverter drive, two-speed AC motor control |
Plastic bags or wooden boxes.
If you have your own satisfied packing,we can customize for you.
Welcome to Cnina to visit our factory.
