APPLICATION
AAAC cable electrical cable specifications is one kind of AAAC . AAAC cable electrical cable specifications is mainly used as bare overhead transmission cable and as primary and secondary distribution cable. AAAC cable electrical cable specifications is also suitable for laying across basins, rivers and valleys where special geographical textures exist.
STANDARD
AAAC cable electrical cable specifications is basic design to ASTM B399 / B399M standard, DIN48201, IEC 60189, BS EN 50182, BS 3242 standard.
CONSTRUCTION
AAAC cable electrical cable specifications is consists of aluminum alloy wires. The aluminum alloy wires are concentrically stranded. This section deals with heat-treatable magnesium silicon type aluminium alloys to the applicable international standard, the electrical and mechanical properties of which all fall within the values suggested by relevant standard. Conductors to all other recognized specifications can also be supplied. The alloys referred to have higher strength but lower conductivity than pure aluminium. Being lighter, alloy conductors can sometimes be used to advantage in place of the more conventional ACSR; Having lower breaking loads than the later, their use becomes particularly favourable when ice and wind loadings are low.
ELECTRICAL PROPERTIES
| Density@20ºC | 2.70 kg/dm |
| Temperature Coefficient@20°C | 0.00360 (°C) |
| Resistivity@20°C | 0.0326 Ohms mm2 /m |
| Linear Expansivity | 23 x10-6 (°C) |
SERVICE CONDITIONS
| Ambient Temperature | -5°C - 50°C |
| Wind Pressure | 80 – 130kg/m2 |
| Seismic Acceleration | 0.12 - 0.05g |
| Isokeraunic Level | 10 – 18 |
| Relative Humidity | 5 – 100% |
Tano Cable aims to providing integral power solution for international customers. We are working together as one company to provide products and technologies for building, maintaining and advancing the power and information infrastructures that connect the world. We mainly have the following products with strong competitiveness: all aluminum conductors (AAC), all aluminum alloy conductors (AAAC), aluminum conductors steel reinforcement (ACSR), , aerial bundled cables (ABC), building wire, welding cable, control cable, instrument cable, rubber cable, PVC insulated power cable, XLPE insulated power cable up to 500KV, customer-tailored cable and cable accessories, conforming to many different Country or international standard, such as IEC, HAR, BS, DIN, ICEA, ASTM, SABS, AS/NZS, JIS and so on.
Tano Cable pays great importance on the quality. We have strong teams and equipment for both production and inspection. Moreover, we were awarded many certificates of ISO, CE, SONCAP, others from China and abr oad. We keep improving our quality management system to meet the client’s final satisfaction
