Metal Oxide Varistor For Lightning Arrester

Name: Metal Oxide Varistor For Lightning Arrester
Brand: Fayun
SKU: 133318457

Negotiable MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

Fayun

Model Number:

D3-D8

Shijiazhuang Fayun Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin or Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name Fayun

Model Number D3-D8

Type Varistor

Technology Metal Oxide

Package Type Surface Mount

Specifications

Metal Oxide Varistor
1.Diameter:35mm-81mm
2.Used:lightning arrester
3.Reference voltage:4.0-5.0kv
4.Used:Distribution Powe

Metal Oxide Varistor For Lightning Arrester

Usage:Used in arrester and insulator,Distribution,power station,Electric machinery

Modle No.	Diameter	Height mm	Voltage at 1mA D.C.	Ratio of residual Voltage at 8/20us lightning impulse and 1mA DC		4/10 μs 2 times high current	18times of 2μs rectangular current impulse	Usage
	mm	mm	KV	5kA	10kA	kA(max.)	kA(max.)
D3	35^+0-1	24^±1	5.0^±0.5	1.85		40	100	Distribution Power Station
D4	42^±1	24^±1	5.0^±0.5	1.8		65	200	Power Station Electric mahinery Parallel complementary capacitor
D5	52^±1	24^±0.5	4.7^±0.5	1.72	1.79	65	400	Power Station Electric mahinery
D6	59^±1	22.5^±0.5	4.5^±0.5	1.66	1.77	100	600
D7	71^+1-0	22.5^±0.5	4.5^±0.5	1.58	1.70	100	800	Power Station
D8	81^+1-0	22.5^±0.5	4.5^±0.5	1.60	1.65	100	1000
