Metal Oxide Varistor For Lightning Arrester
- Tianjin or Shanghai
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | FaYun | |
| Model Number | D3 | Type | Varistor | |
| Technology | Metal Oxide | Package Type | Other, Other, Surface Mount |
Product Description
Specifications
Metal Oxide Varistor For Lightning Arrester1.Diameter:35mm
2.Height:3-31mm
3.Volatage:0.7-6.8KV
4.Usage;usde arrester
Metal Oxide Varistor is the core of the arrester.
Metal Oxide Varistor is the core of the arrester, which main component is Zinc Oxide and with a small quantity of bismuth Oxide, fluoride oxide, manganous carbonate, antimony oxide and other gleam of additive and made with high temperature.
As zinc oxide varistor has a good voltage-ampere (Non-linearity) characteristic, hence the zinc oxide varistor is a very important components applied to surge arrester
Specification |
| MOV32×25 | MOV32×31 | MOV35×3 | MOV35×6 | MOV35×21 | |
Diameter | mm | 32±1 | 32±1 | 35±1 | 35±1 | 35±1 | |
Thickness | mm | 25±1 | 31±1 | 3±1 | 6±1 | 21±1 | |
D.C. reference voltage (U1mA) | kV | 5.6±0.3 | 6.8±0.3 | 0.7±0.1 | 1.4±0.2 | 4.6±0.3 | |
Leakage current under 75%U1mA | uA | <10 | <10 | <10 | <10 | <10 | |
Max. ratio of residual voltage (8/20us) |
| 1.80 @5kA | 1.80 @5kA | 1.83 @1.5kA | 1.83 @1.5kA | 1.78 @5kA | |
Current impulse withstand capability | 4/10us | kA | 65 | 65 | 10 | 10 | 65 |
2ms | A | 120 | 120 | 100 | 100 | 150 | |
Recommended rated voltage | kV | 3.8 | 4.5 | 0.28 | 0.50 | 3.0 | |
Recommended continuous operating voltage | kV | 3.0 | 3.6 | 0.22 | 0.40 | 2.4 | |
