Silicon Rubber Post Insulator

Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

Model Number:

FXBW

Shijiazhuang Fayun Electric Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name FY

Model Number FXBW

Type Insulator

Material Composite Polymer

Application High Voltage

Rated Voltage 10-220KV

Specifications

Insulator
1.Rated voltage:10KV~220KV
2.Meterial: Silicon rubber
3.IEC standard
petive price

Post type insulator:

Specifications of post insulator:

1.Electrical post insulator
2: KEMA test report
3.Color:Brown White Grey
4.Managerment System: ISO9001-2000

No.	Insulator Mode	Rated Voltage kV	System Nominal Voltage Kv	Rated machinery Lode of no less than		Total Height mm	Insulation Distance mm	Minimum nominal Creepage Distance mm	1 min Frequency tolerance Voltage≥kV		Lightning shock wave tolerance Voltage ≥kV	Annex on the size of the installation			Under Annex install size
				Bending	Reverse				Dry	Wetlands		Hole Center Diameter	Aperture	Drill holes	Hole Center Diameter	Aperture	Drill holes
				kN	kN·m							mm	mm		mm	mm
1	FZS-12/4T	12	10	4	0.6	215	115	190	47	42	75	36	M8	2	130	12	2
2	FZSW-24/8	24	20	8	1.2	350	205	385	68	50	125	76	M12	4	76	M12	4
3	FZSW-24/16	24	20	16	6	350	205	385	68	50	125	76	M12	4	76	M12	4
4	FZSW-40.5/4	40.5	35	4	1.5	445	300	650	108	95	230	76	M12	4	76	M12	4
5	FZSW-40.5/8	40.5	35	8	2	445	300	650	108	95	230	76	M12	4	76	M12	4
6	FZSW-72.5/4	72.5	66	4	2	770	620	1160	200	185	410	127	M16	4	127	M16	4
7	FZSW-72.5/6	72.5	66	6	2.5	70	620	1160	200	185	410	127	M16	4	127	M16	4
8	FZSW-126/4	126	110	4	3	1220	1070	2015	280	230	550	127	M16	4	178	18	4
9	FZSW-126/8	126	110	8	4	1220	1050	2015	280	230	550	127	M16	4	200	18	4
10	FZSW-126/12.5	126	110	12.5	6	1220	1050	2015	280	230	550	127	M16	4	254	18	8
11	FZSW-252/4	252	220	4	3	2300	1940	4030	560	395	1000	127	M16	4	200	18	4
12	FZSW-252/8	252	220	8	4	2300	1940	4030	560	395	1000	225	18	4	254	18	8
13	FZSW-252/12.5	252	220	12.5	6	2300	1940	4030	560	395	1000	225	18	4	275	18	8
14	FZSW-252/6	252	220	16	6	2300	1940	4030	560	395	1000	225	18	4	300	18	8
