Home > Light Industry & Daily Use > Exhibition and Advertising Equipment > Other Exhibition and Advertising Equipment > Video Wall

Video Wall

Name: Video Wall
Brand: PROPD
SKU: 133312689

US$ 1 - 2,000 MOQ: 1 Piece

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

PROPD

Model Number:

ETP-46-UN

Contact Supplier Request Quote Chat Now

Shenzhen Yitelang Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name PROPD

Model Number ETP-46-UN

Type TFT

Application Indoor

Panel Size 46''

Max Resolution 1920*1080

Viewing Angle 178°

Pixel Pitch 0.7455(H)X0.7455(V)

Color 8 Bit

Contrast Ratio 3000:1

Brightness 700CD/M2, 700cd

Response Time 8ms

Dimension

Model	ETP-46-UN	ETP-47-UN	ETP-55-UN	ETP-60-UN
Resolution ratio	1366*768P	1920*1080P		1365*768P
Appreance size	1025.6580105mm	1046.8591.693.5mm	1215.4686.1122mm	1322.3745.771mm
Display area	1018.9*573.3mm	1039.87*584.64mm	1209.9*680.6mm	1318.6*741.9mm
Maximum power	250W	250W	350W	500W
Rated Power	180W	180W	280W	420W
Bilateral splicing seam	6.7mm	6.3mm	5.3mm	2.8mm
Total weight	24.7KG	25.4KG	34.6KG	26.3KG
Brightness	700cd/m2			1700cd/m2
Contrast	3000:1			1000000:1
Reponse time	8ms			0.001ms
Visual angle	178°			179°
Line frequency	65-70Hz			Subdomain drive 600Hz
Field frequency	60Hz			Subdomain drive 600Hz
Color system	PAL/NTSC
Input/Output	1Vp-p, 75 Ω ,BNC×2
HDMI/DVI/VGA input	×1
Communiation interface	Rs232 loops input/output
Power	AC110V-240V, 50/60Hz
Temperature	0-60°C
Humidity	10%~90%
Operation	PC control software for the big screen
Cooling	Intelligent temperature control cooling system
Case Material	SPCC
Installation	Cabinet type/Floor-type/Wall-mounted

Photo Show

Certificate

About product

Characters of ETP - 46 - UN super-slim splicing screen : (1) Flat-fell seam between the non-display area is only 5.3 mm; (2) Using Yitelang image point pixel dynamic cutting processing technology to compensate for the details of image, it can make the low pixel image display clearly; (3) The screen bodies use unified international multinational group three major brands such as Samsung, LG and Sharp and so on; (4) LCD product itself with low power consumption and last much longer. (5) Through RS232 serial port to realize the remote control function; rapid response identification technology, to ensure that the video will play smoothly and pictures show without distortion; (6). Service life of this product can up to 50000 hours, a new ultra wide angle of view extension technology, which comprehensively ensures the image in the display angle without distortion and deformation.
