Product Details
Place of Origin: | Guangdong, China | Brand Name: | YONGKUNTAI TIANXIANG | Model Number: | RVV (diameter of CCA wire:0.18mm) |
Insulation Material: | PVC | Type: | Low Voltage | Application: | Other, 3 core power cord for household appliances,i.e.conditioner,etc. |
Conductor Material: | Other, copper clad aluminum | Jacket: | PVC |
Product Description
Specifications
1)PVC insulated&sheathed2)Copper clad aluminum 0.18mm
3)Size:0.5-0.75-1-1.5-2.5-4-6sqmm
4)Free samples,fast delivery
CCA cables
Free samples,fast delivery
What is CCA?
Copper clad aluminium wire, commonly abbreviated as CCAW or CCA, is an electrical conductor composed of an inner aluminium core and outer copper cladding.
3 core CCA cables :orange sheath
3 core CCA cables :black sheath
*Kindly note that also we can make cables and wires according to your requirements.
1)Product Name: PVC insulated and sheathed copper clad aluminum electric wires and cables
2)Model No.:RVV
3)Number of cores:3
4) Cross-sectional Area---No.of Wires/Diameter
3×0.5mm²---16/0.18mm
3×0.75mm²---24/0.18mm
3×1mm²---32/0.18mm
3×1.5mm²---48/0.18mm
3×2.5mm²---80/0.18mm
3×4mm²---128/0.18mm
3×6mm²---192/0.18mm
5)Conductor Material:copper clad aluminum
6)Insulation Material: PVC (Polyvinyl Chloride)
Color: red,black,white,cream,yellow,bule,green,brown,green/yellow or as you require
7)Sheath Material: PVC (Polyvinyl Chloride)
Color: black,white,orange or as you require
8)Rated Voltage: 300/500V
9) Rated Temperature: 0°C to 70 °C
10)Usage:Mainly used at middle and light style moving electronics, home appliances, power and lighting and the places where flexible required.
11)Our company can accept all trading manners, e.g EXW,FOB,CIF,DDP,DDU. etc….
We can also accept any kinds of payment terms, such as TT,L/C,D/P,O/A, Western Union, etc…
12) We are going to load your goods.
Our factory is loacted in Shenzhen,Guangdong,China.
Packing--(size from 3×0.5mm² to 3×2.5mm² )
1-paper reel
2-plastic reel
3-metal reel
4-plastic film (free)
5-plastic bag+belt
Packing--(size above 3×4mm²)
Option1-inside plastic film,outside several rolls in one carton
Option2-inside plastic film,outside PP bag
Option3-plywood reel
Stock house
Our factory
*Kindly note that also we can make cables according to your requirements.
