2015 new small oem laser qr pdf417 datamatrix 2D barcode scan module
Model | AC3100 |
Interface | Upto 25 in./63.5cm per second USB: HID Keyboard(default mode), COM Port Emulation Rs232: Standard |
Light source | Aimer: 617nm LED Illumination: 625nm LEDs |
Field of View | 39°(H)x25°(V) |
Roll Pitch Yaw | 0-360° ±65° or greater ±60° or greater |
Print Contrast | 25% minimum |
1D | UPC/EAN,UPC/EAN with supplementals, Bookland EAN, ISSN, UCC Coupon Extended Code, Code 128, GS1-128, ISBT128, Code 39, Code 39 Full ASCII, Trioptic Code 39, Code 32, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, GS1 DataBar variants, Korean 3 of 5, ISBT Concat |
2D | PDF 417, MicroPDF 417, Composite Codes Data Matrix, Maxicode, QR Code, MicroQR, Aztec |
connector | FPC 16pin 0.5Pitch 8.5mm |
Power | 5VDC± 10% @260mA |
Weight | 10g |
Dimensions | Engine: (W)12 x (L) 31.5 x 12mm |
Decode board: (W)19 x (L) 38 x 8mm | |
Operating temperature | 0 to 50°C |
Storage temperature | -40 to 70°C |
Relative Humidity | 5% to 95%(non-condensing) |
Drop spec | Withstands 10Gs 0.06” Double amp |
Ambient Light Immunity | Immune to normal indoor lighting up to 1600Lux. Immune to sunlight up to 86000Lux. |
