Specifications
electric capstan winches, fishing boats capstan hot sale1.ISO 9001: 2000
2.Awarded by CCS.
electric capstan winches, fishing boats capstan hot sale
Don't be afraid of these questions, it is great help for us to offer best recommendation and price.
Capstan
1.Working load/Capacity ?
2.Diameter of chain/rope ?
3.Power Source:Electric or hydraulic ?
4.Vertical or horizontal type ?
5.is also anchor windlass capstan?
6.Rotating speed?
|
Name |
Warping Load(KN) |
Warping Speed(m/min) |
Wire Dia.(mm) |
Motor power(KW) |
|
Electric | |||||
|
5kN Electric (Hydraulic) Mooring Rope Capstan |
5 |
≥18 |
Φ11 |
3/1.2 |
|
|
10kN Electric (Hydraulic) Mooring Rope Capstan |
10 |
≥18 |
Φ11 |
4.3/1.7 |
|
|
15kN Electric (Hydraulic) Mooring Rope Capstan |
15 |
≥18 |
Φ13 |
8.5/3.5 |
|
|
20kN Electric (Hydraulic) Mooring Rope Capstan |
20
|
≥18 |
Φ15 |
11/11/7.5 |
|
|
30kN Electric (Hydraulic) Mooring Rope Capstan |
30 |
≥18 |
Φ17.5 |
16/16/11 |
|
|
50kN Electric (Hydraulic) Mooring Rope Capstan |
50 |
≥18 |
Φ20.5 |
16 |
|
|
70kN Electric (Hydraulic) Mooring Rope Capstan |
70 |
≥15 |
Φ26 |
22 |
|
|
100kN Electric (Hydraulic) Mooring Rope Capstan |
100 |
≥15 |
Φ28 |
45/45/30 |
|
|
120kN Electric (Hydraulic) Mooring Rope Capstan |
120 |
≥15 |
Φ32.5 |
60/60/45 |
|
|
150kN Electric (Hydraulic) Mooring Rope Capstan |
150 |
≥15 |
Φ36.5 |
60/60/45 |
|
|
200kN Electric (Hydraulic) Mooring Rope Capstan |
200 |
≥15 |
Φ40 |
75/75/36 |
|
|
250kN Electric (Hydraulic) Mooring Rope Capstan |
250 |
≥12 |
Φ46 |
75/75/36 |
|
Note: Specific technical parameters take technical specifications and drawing as standard
Power Supply:
Electric, Hydraulic,Diesel, Electric combined hydraulic,Diesel combined hydraulic type
Our Advantage
1.High efficiency development based on our stronge team;
2.Supply high quality standard goods with competitive price;
3.Professional service for customer;
4.Delivery goods on time
