1080P Full HD 2MP Water & Vandal-proof H.265 WDR Smart IR Dome Network Camera

Model

IPC-VI5721FWD-EIZ

Camera

Image Sensor

1/2.8” 2Megapixel progressive scan CMOS

Effective Pixels

1920(H)x1080(V)

RAM/ROM

512MB/32MB

Scanning System

Progressive

Min. Illumination

0.006Lux/F1.4 (Color); 0Lux/F1.4 (IR on)

S/N Ratio

More than 50dB

IR Distance

Distance up to 50m (164ft)

IR On/Off Control

IR LEDs

Lens

Lens Type

Motorized/ Auto Iris(DC)

Mount Type

Board-in

Focal Length

2.7mm~12mm

Max. Aperture

F1.4

Angle of View

H: 97~34 , V: 52~20

Optical Zoom

4x

Focus Control

Motorized

Close Focus Distance

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:0~355; Tilt:0~65; Rotation:0~355

Intelligence

IVS (optional)

Tripwire, Intrusion, Object Abandoned/Missing

Advanced Intelligent Functions

Face Detection

Video

Compression

H.265+/H.265/H.264+/H.264

Streaming Capability

Resolution

1080P(1920x1080)/1.3M(1280x960)/ 720P(1280×720)/D1(704×576/704×480)/

VGA(640×480)/CIF(352×288/352×240)

Frame Rate

Main Stream

1080P (1~50/60fps)

Sub Stream

D1(1~25/30fps)

Third Stream

1080P(1~25/30fps)

Bit Rate Control

H.264: 24~10240Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

White Balance

Gain Control

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization

N/A

Smart IR

Support

Defog

N/A

Digital Zoom

16x

Flip

0/90/180/270

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

G.711a/ G.711Mu/ AAC/ G.726

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

HTTP; HTTPs; TCP; ARP; RTSP; RTP; UDP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; QoS; UPnP; NTP; Bonjour; 802.1x; Multicast; ICMP; IGMP; SNMP

Interoperability

ONVIF,PSIA,CGI

Streaming Method

Unicast / Multicast

Max. User Access

10 Users /20 Users

Edge Storage

Local PC for instant recording

Micro SD card 128GB

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, Easy4ip

Smart Phone

IOS, Android

Certifications

Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Interface

Video Interface

N/A

Audio Interface

1/1 channel In/Out

RS485

N/A

Alarm

1/1 channel In/Out

Electrical

Power Supply

DC12V, AC24V, PoE(802.3af)(Class 0)

Power Consumption

<12.5W

Environmental

Operating Conditions

-30 C ~ +60 C (-22 F ~ +140 F) / Less than 95% RH

Storage Conditions

-30 C ~ +60 C (-22 F ~ +140 F) / Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

IK10

Construction

Casing

Metal

Dimensions

Φ159.1mm×117.9mm (6.26”×4.64”)

Net Weight

0.89kg (1.96lb)

Gross Weight

1.13kg (2.49lb)
