Specifications
sc fiber optical patchcord1.material:LSZH/PVC/PU
2.for FTTH/FTTP/FTTX
3.LC/FC/ST/SC connectors
4.CE ,ROHS and ISO
SC-SC Singlemode Simplex Patchcord
Characteristics:
1. Low insertion loss, high return loss
2. Good compatibility
3. High precision of mechanical dimensions
4. High reliability & stability
5. PC,APC,UPC optional, cable length optional
6. Single-mode cable: yellow; multi-mode cable: orange; options available for other colors
Applications:
1. Local Area Networks, including FTTH and FTTD
2. CATV System
3. Telecommunication Networks
4. Data processing networks
Specification:
1. Insertion loss: ≤0.2dB
2. Return loss: ≥50dB(PC)
3. Repeatable: 0.1dB (1000)
4. Temperature range: -40°~80°C
Ordering Information:
SC/ PC–SC/ PC/ SM/ 1C/ 3.0–2M Armored Armored Fiber Optic Patch Cord
1. Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA
2. Ferrule End-face: PC, UPC, APC
3. Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
4. Cable Quantity: “1C” means one core or Simplex(SX)
5. Cable Diameter: 3.0mm, 2.0mm, 0.9mm
6. Cable Length: 1, 2, 3 meter or customized
7. Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum
Other detail about FO pull patch cord:
