Specifications
fiber optic patch cord1.material:LSOH
2.for FTTH/FTTP/FTTX
3.LC/FC/ST/SC connectors
4.Insert loss <= 0.2 dB/manufacturer
fiber optic FC patch cord for FTTH/FTTX/FTTP
Patch cord have normal single mode/multi mode Silica patch cord, also can partition as Connector structure, such as FC/SC/ST/LC/MTRJ/MPO/MU/SMA/E2000/DIN and etc.., common FO patch cords have FC-FC,FC-SC,FC-LC,FC-ST,SC-SC,SC-ST, quantity of optical fiber patch cord core,length, physical structure as your design.used High precision grinding machine.
Environmental Reliability Test
The performance of the patchcords has been carefully designed to meet the IEC standards, GR-326-CORE, in the test of optical characteristics, vibration test, thermal cycling, impact resistance, salt spray erosion, thermal aging, humidity resistance and others
Applied range
optical fiber communication system
optical access network
Optic-fiber Date Communication
Optical-fiber CATV
A local area network (LAN)
Test Equipment
Technical parameters
connector types: FC, SC, LC, STand etc
The min bending radius: 3.8 cm
Operating temperature range: - 40 ~ 85 °C
connector materials: ceramic plug core
Min bandwidth: 200 MHZ. Km / 850 nm, 500 MHZ. Km / 1300 nm
Repeat plug: < 0.2 dB, each 500 times plug
Min reflection loss: 20 db
Max return loss:-50dB
Other types about FO patch cord:
