optical fiber adapter used in ftth solution
- 10000 Piece / Pieces per Month
- Shenzhen
- Credit Card PayPal
Product Details
Place of Origin: | Guangdong, China | Brand Name: | HYG | Model Number: | HYG-ad-0372 |
Packaging Details
Plastic bags in carton or as customer's requirement.
Product Description
Manufacturer DIN optical adapter for patch cord and connectors and other equipments in FTTH,FTTX and communication network
DIN optical adapter
1.Certified Company&OEM
2.CE/ISO/ROSH certified
3.High dimensional&accuracy
4.Manufacturer low quotation
DIN optical adapter parameters:
1. Simplex and duplex panel cutouts
2. Panel clip for easy installation
3. Increase panel density and quick plug in installation
4. Available in several standard colors
5. Meet bellcore GR-326 standard
6. Insertion loss: SM<0.3dB, MM<0.5dB
7. Durability (500 Mating): 0.2dB Max Increase
8. Operating temperature: -40°C~85°C
9. Storage temperature: -40°C~85°C
10. Cable type: PVC, LSZH, OM3, OFNR, OFNP
Item | Mounting | Sleeve Material | Adapter Material | Colour |
SM/PC Simplex | 2 Flange | Zirconia Ceramic | Plastic | Blue |
SM(APC8o) Simplex | 2 Flange | Zirconia Ceramic | Plastic | Green |
SM/PC Duplex | 2 Flange | Zirconia Ceramic | Plastic | Blue |
SM(APC8o) Duplex | 2 Flange | Zirconia Ceramic | Plastic | Green |
SM/PC Duplex | 2 Flange | Zirconia Ceramic | Plastic | Blue |
SM/PC Simplex | 2 Flange | Zirconia Ceramic | Plastic | Blue |
MM/PC Simplex | 2 Flange | Ceramic/ phosphor bronze | Plastic | Beige |
MM/PC Duplex | 2 Flange | Ceramic/ phosphor bronze | Plastic | Beige |
MM/PC Duplex | 2 Flange | Ceramic/phosphor bronze | Plastic | Beige |
CATV System
Company Profile
About HYG Optics
The Haiyu Optics, founded in 2000, is focus on design and manufactured fiber optic communication products. It has developed a range of products including Indoor and outdoor optical cables, fiber optic jumpers, pigtails, connectors and adapters, network solution equipment like optic media converters, attenuators, tranceivers, optical models and other accessories. Widely used in telecom communication, mobile communication, network solution, radio and television, etc.
HYG Quality Assurance
Our ISO9001:2008 certified quality management systems have been refined for flexibility and efficiency, and produce a high quality, high reliability, low cost and diverse product range. Other quality system we complying with ISO14001, CE, Rohs and 5S system.
Advanced high precision test equipment: Insertion and return loss tester, 3D Interferometer.
The location
The company is located in Shenzhen, near by Hongkong, enjoying the convenient transportation. Our products are exported to USA, Germany, France, Russia, the UAE, Indonesia and so on. For our long-term development, our company cooperates with Corning, OFS, YFOC, CCTC, etc.
Our mission
QUALITY TO SURVIVE, INNOVATION FOR DEVELOPMENT.
