Specifications
FO SC adapter1.material:ceramic
2.repeatability:>=1000 times
3.insert loss:SM<=0.2dB,MM>=0.3dB
4.CE and ROSH
Sc/pc Single Mode Simplex Fiber Adaptor FOR network
Our company from the United States and Japan imported from optical passive components production assembly equipment and testing instrument, the formation of optical passive production line. At present, can provide traditional FC, SC, ST fiber connector and LC, double SC, MT - RJ, MU such as small optical fiber connector, all provide optical fiber connection activities connector all through the ministry of information industry optical communication product quality supervision and inspection center for qualified.
Product characteristic
compatibility, repeatability
high precision size has good compatibility
resistance to friction ceramic casing
environmental stability good
card lock plug
provide separate ST type, SC type, FC type, LC type and so on many kinds of adapter
Application
any optical fiber connection
fiber to the home, optical fiber sensors, testing instruments, such as optical fiber point
technical parameters
material:ceramic
repeatability: ≥1000 times
insert loss: SM ≤0.2 dB, MM ≤ 0.3 dB
compatibility: ≤ 0.2 dB
Optical Parameter |
W/Japanese Ceramic Sleeve |
W/Chinese Ceramic Sleeve |
W/P.B Sleeve |
Insertion Loss |
<0.1 dB |
<0.2dB |
<0.3dB |
Durability |
<0.10 dB typical change,1000 times |
<0.2dB typical change,1000 times |
<0.30 dB typical change,500 times |
Operating Temp |
-20~75°C |
||
Storage Temp. |
-40~85°C |
||
Other types adapter:
