Long Range Rfid UHF Reader and Controller for Vehicle/Parking
Model Number : JYA-LR0703
Introduction :
JYA-LR0703 is a high performance UHF RFID integrated reader. It is designed upon fully self-intellectual property. Based on proprietary efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, anti-counterfeit and industrial production process control system.
Main Features :
.Self-intellectual property;
.Support ISO18000-6B, ISO18000-6C(EPC C1G2) protocol tag
.902~928MHz frequency band(frequency customization optional)
.FHSS or Fix Frequency transmission
.RF output power up to 30dbm(adjustable)
.12dbi antenna optional with effect distance up to 8m-15m
.Support auto-running, interactive and trigger-activating work mode
.Low power dissipation with single +9 DC power supply
.Support RS232, RS485, Wiegand interface
Passive 860Mhz-960Mhz UHF RFID Reader Module with 15m Long Range
Main specification :
l Absolute Maximum Rating
ITEM |
SYMBOL |
VALUE |
UNIT |
Power Supply |
VCC |
16 |
V |
Operating Temp. |
TOPR |
-10~+55 |
°C |
Storage Temp. |
TSTR |
-20~+75 |
°C |
l Electrical and Mechanical Specification
Under TA=25°C,VCC=+9V unless specified
ITEM |
SYMBOL |
MIN |
TYP |
MAX |
UNIT |
Power Supply |
VCC |
8 |
9 |
12 |
V |
Current Dissipation |
IC |
|
350 |
650 |
mA |
Frequency |
FREQ |
902 |
|
928 |
MHz |
