Common Cartridge Heater With External Lead Wire

Common Cartridge Heater With External Lead Wire thumbnail-1
Common Cartridge Heater With External Lead Wire photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
shenzhouyb
Type:
Heating Tube
Contact Supplier Request Quote Chat Now
Shaoxing Shangyu Shenzhou Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name shenzhouyb
Type Heating Tube
Application Heater Parts
Certification Other, ISO9001



Specifications



1)Resistance wire OCr20Ni80, 2)Min.dia.3mm,length:30mm. 3)high density cartridge heater. 4)ss304/316 sheath. 5)10~25w/cm



common cartridge heater with external lead wire





Mostly cartridge heater is used for heating up solids such as injection presses heating plates or various tools, cartridge heater  can also be used for heating up water of gases under certain conditions. Widely used for manufacturing plastic and rubber parts in the car industry or in the food processing industry, etc . cartridge heaters are also commonly found in the chemical, electronics, medical equipment, packing and nuclear industries

Various cartridge heater technologies are available. The choice of technology will depend on technical specifications required and the application. Unless you know exactly which product you are looking for, we will recommend you the best solution for your needs.





Technical Detail:



1 Tube diameter: Φ3mm-Φ30mm

2 Tube Material:SS304;SS316,SS321,NICOLOY800 etc

3 Insulation Material:High-purity Mgo

4 Reisistance wire element:Ni-Cr or FeCr

5 Lead Connection Option: Crimped or Swaged leads

6 Lead and type of connection leads, 10" Fiberglass Standard(Wire options,silicone high temperature frberglass).



Heat intensity

Not exceeding 30Wcm2 (advisable)

Power

Depends on the dimension

Escape of current (when cold)

<=0.1mA a 242 v.

Insulation (when cold)

5 Min Ohmios 500 Watts minimum

Dielectric strength

1500v. 1/seg

Working temperature

750ºG max.

Tolerance of length

+/-1.5%

Tolerance of diameter

-0.01 a -0.06 m/m

Tolerance of cut of connexion

+/-15 mlm

Power tolerance (w)

5 % - 10 %

Cold areas

Depends on length and diameter 5-25mm







 Feature:



Commom cartridge can be devideded :



1) High power density (heat area sufuce power 10~25w/cm2)

Working temperature≤450 degrees.



2) Middle,low power density (heat area sufuce power 5~11/cm2)

working temperature≤ 300 degrees

 Votage:12~250V (or as requirment)





High Density Construction  High-quality stainless steel construction provides long-lasting protection even in the most rugged industrial environments



Protected with a stainless steel sheath, their watt density can reach 50 W/cm2 and their operating temperature can go up to 800°C.



common cartridge heater with external lead wire
