These lathes are suitable for turning internal and external cylindrical,Conical and other swing surfaces as well as various metric,lnch,module and diametric pitch threads.They can also be used for broaching oil grooves and keyways.There are also following features:
1.The side wall of bed is constructed with coublerib plates.and the shape of internal ribs is of box type and bevel ribs combination.The rigidity is higher than that of ordinary lathes.The precision is stable.And these lathes can carry out strong force cutting.
2.On apron,there is a device,operated by a single lever,used for rapid traverse of the carriage.Spindle's braking and rotating directionchange is controlled by hydraulic system,or by hand operation,all to user's choice.
3.The saddle guide way is glued by "TSF" soft belt wear resisting materials.
4.On user's demand,we can equip the lathe with automatic feeding mechanism.The top slide can be used independently for turning of short cone.In combination with longitudinal feeding,it can also turn long taper surface.
Capacities |
Unit |
CW6180 CW61100 |
Swing over bed |
mm |
800 1000 |
Swing over carriage |
mm |
480 680 |
Maximum length of work piece |
mm |
1000/1500/2000/3000/4000/5000/6000 |
Maximum turning length |
mm |
850/1350/1850/2850/3850/4850/5850 |
Width of guide way |
mm |
600 |
Spindle |
|
|
Spindle nose code |
mm |
C11 (C15 ) |
Diameter of spindle thru hole |
mm |
100 (140) |
Taper hole of spindle |
|
01:20 |
Taper hole of tailstock quill |
|
morse6 |
Number of forward turning speeds |
|
18 kinds |
Number of reverse turning speeds |
|
6 kinds |
Spindle speed Forward |
r/min |
5.5 ~ 750 |
Spindle speed Reverse |
r/min |
10 ~ 775 |
Feed motion |
|
|
longitudinal and cross |
|
64;0.1~ 24.32 |
Cross-to-longitudinal feed rate |
|
½ |
Screw pitch of lead screw |
mm |
12 |
Number and range of metric thread |
|
50;1 ~ 240 (mm) |
Number and range of inch thread |
|
26;14 ~ 1 (tooth /inch) |
Number and range of module thread |
|
53;0.5 ~ 120 (mm ) |
Number and range of diametrical pitch thread |
|
24 ;28 ~ 1 (tooth / inch) |
Rapid traverse speed of carriage |
mm/min |
4000 |
Tool post |
|
|
Distance between spindle center-line and tool resting plane |
mm |
33 |
Size of tool shank |
mm |
32 |
Tool post swing range |
|
±90° |
Max. travel of top slide |
mm |
200 |
Max. travel of cross slide |
mm |
500 |
Tailstock |
|
|
Diameter of Tailstock quill |
mm |
100 |
Travel of tailstock quill |
mm |
250 |
Taper hole of tailstock quill |
|
morse6 |
