Specifications
convenient,high quality,flexible,easy to operate and maintain,power saving,full automation,efficient,wide-ranging application
1. Application Scope:
This series of flat screen printing machine is suitable for large format printing paper products, light guide plate, simulation oil painting, New Year paintings precision screen printing
2. Characteristics:
1)Printing transmission is driven by the electric motor,synchronous belt drive.
2)Action sensitive, speed can be adjusted. Machine up and down is driven by the electric motor, frequency control. Smooth operation.
3)Scraper and scraping blade have a air pressure governor, the thickness of the printing can be adjusted.
4) Vacuum adsorption print.
5)The working table has a vernier regulation system(can move up and down, left and right ,forward and backward)that makes registration more correctly and simply.
6) With security devices to make the head printing stop on the upper part position that is more reliable and safer.
7) The electronic control unit(ECU)is central control by the microcomputer, the operation of complete applicance is simpler and more flexible, easy to maintain.
3. technical parameters:
Model |
YKP120140 |
Workbench Area (mm²) |
1400×1600 |
Max Print Area (mm²) |
1200×1400 |
Max Screen Size(mm) |
1550×1700 |
Min Screen Size(mm) |
550×650 |
Thickness of printing stock(mm) |
20 |
Printing Speed (pcs/h) |
400~900 |
Operation Air Pressure (Mpa) |
0.4~0.8 |
Air Consumption (0.6Mpa)(L/pcs) |
13 |
Source Power (kw) |
5.5 |
Max Table Height(to floor)(mm) |
880 |
Dimension (mm) L×W×H |
2480×1700×1380 |
Weight (kg) |
660 |
Rated Power (V/Hz) |
220/50 |
