Home > Products > semi-auto screen printer > Desktop Vacuum small printing press for sale
Desktop Vacuum small printing press for sale
- 100 Set / Sets per Month
- shenzhen
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Place of Origin: | Guangdong, China | Brand Name: | scien-art |
Model Number: | YKP-2030P | Usage: | Paper Printer, Label Printer, Card Printer, Tube Printer, Bill Printer, Cloths Printer, Other, Paper Printer, Label Printer, Card Printer, Tube Printer, Bill Printer, Cloths Printer, cellphone glass cover screen printer | Automatic Grade: | Semi-Automatic |
Voltage: | 110V/220V | Gross Power: | 50W | Dimensions(L*W*H): | 93x74x87CM |
Weight: | 125KG | Certification: | / | Warranty: | 1YEAR |
After-sales Service Provided: | Overseas third-party support available |
Product Description
Specifications
1.high quality and mature technology flat silk screen printing machine2.Brand assurance
3.Stable performance/ high accuracy
This samll vacuum screen printing machine is modified on the basic of HC-2030C mini screen printer , it have two flat choce-one is use the T-solt falt and the other is use the vaccum falt.This machine vacuum working table is electroplated to be rust-proof, and it has the features of quick speed,steady performance ,high precision,which can compose the production line in the small workshop or in samll space.The machine especially fit for use in the vc ,paper ,all kinds of wood,name card,eye glass,silica gel key-press screen print and so on.
Features
1.SCM IC coordinate light touching panel to complile action programming
2.Adopt stainless steel cabinet to protect machine body , and its vacuum working table is electroplated to be rust-proof.
3.Auto 4-digit counter built-in, counting printing quantity
4.Airframe adopts coin alloy,and metal coating surface
5.distyle vertical constructure, high precision, steady operation
6.the transeversa stroke can be adjusted, spacing by Taiwan electronic switch
7.the angle of scraper and ink covering blades can be adjusted randomly
8.installing scraper constant pressure equipment to make sure pressure is steady when printing
8.you can regulate work-table back and forth or right and left, and then fastening it
10.you can regulate screen frame back and forth, right and left or level orientatio
11.vacuum stainless steel worktable, it can absorb kinds of film products
12.installing CEC oil buffer on up and down, left and righ to avoid printing shock
13.The machine is running fastly, steably and lower noise.
14.Action model option: fully automatic | semi-automatic | manual
15.Start-up method:panel | foot switches
16.scraper pressure controller:by pressure regulating Valve
17.vertical driving style: pneumatic
Specification
1.Mode:DY-2030P
2.Print area:200x300mm
3.Max height of printing products: 100mm
4.transeversa stroke: 300MM
5.vertical stroke: 160MM
table size: 250x450mm
7.Printing speed:1200pcs/hour
8.power:110V/200V 50/60Hz 50W
9.Machine Size:93x74x87CM
10.Packing size: 104x98x84CM(L*W*H)
11.Net Weight:125KG
12.Gross Weight: 160KG
We can manufacture according to customer’s requirements
