Home > Industrial Equipment & Components > Cutter & Tongs > Reamer > Din311 Bridge Reamer High Speed Steel HSSCobalt
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
STC
Model Number:
U30
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hand Expansion Reamer DIN859 High Speed SteelNegotiableMOQ: 50 Pieces -
Hand Reamer High Speed Steel HSS HSSCobaltUS$ 0.5 - 10MOQ: 50 Pieces
-
Morse Taper Shank Machine Chucking ReamerNegotiableMOQ: 50 Pieces
-
Din212 ISO521 Straight Shank Reamer High Speed SteelNegotiableMOQ: 100 Pieces
-
Helical Taper Pin Reamer High Speed SteelNegotiableMOQ: 50 Pieces
Place of Origin
Jiangsu, China
Brand Name
STC
Model Number
U30
Material
Other
Type
Other, Bridge Reamer, Drilling Tool
Bridge Reamers,DIN311,HSS
High Speed Steel
Taper Shank, Long Body.
Straight flute or spiral flute.
Standard: DIN311, ISO2238.
Size:7/16" to 2", 8.4mm-37mm.
Tolerance: H7,H8.
Bridge Reamers are designed for use in structural steel, in the building industry, bridge erection, and ship construction. The cutting end of the flutes is tapered therefore allowing the reamer not only to enter overlapping holes but also permits insertion into very badly misaligned holes. Bridge Reamers are commonly used in portable electric or pneumatic machines.
Ø D | L | l | l1 | Morse | Flute | Weight |
8,4 | 161 | 85 | 25 | 1 | 4 | 0,085 |
9,5 | 166 | 90 | 27 | 1 | 4 | 0,090 |
10,0 | 171 | 95 | 30 | 1 | 4 | 0,095 |
11,0 | 176 | 100 | 33 | 1 | 4 | 0,100 |
12,0 | 199 | 105 | 39 | 2 | 4 | 0,210 |
13,0 | 199 | 105 | 39 | 2 | 4 | 0,210 |
14,0 | 209 | 115 | 42 | 2 | 4 | 0,240 |
15,0 | 219 | 125 | 45 | 2 | 4 | 0,280 |
16,0 | 229 | 135 | 48 | 2 | 4 | 0,320 |
17,0 | 251 | 135 | 51 | 3 | 4 | 0,380 |
18,0 | 261 | 145 | 58 | 3 | 4 | 0,400 |
19,0 | 261 | 145 | 58 | 3 | 4 | 0,420 |
20,0 | 271 | 155 | 62 | 3 | 4 | 0,520 |
21,0 | 271 | 155 | 62 | 3 | 4 | 0,630 |
22,0 | 281 | 165 | 66 | 3 | 4 | 0,650 |
23,0 | 281 | 165 | 66 | 3 | 4 | 0,660 |
24,0 | 296 | 180 | 72 | 3 | 4 | 0,740 |
25,0 | 296 | 180 | 72 | 3 | 4 | 0,780 |
26,0 | 296 | 180 | 72 | 3 | 4 | 0,820 |
27,0 | 311 | 195 | 78 | 3 | 4 | 0,900 |
28,0 | 311 | 195 | 78 | 3 | 4 | 0,930 |
29,0 | 311 | 195 | 78 | 3 | 4 | 0,960 |
30,0 | 311 | 195 | 78 | 3 | 4 | 1,070 |
31,0 | 326 | 210 | 84 | 3 | 4 | 1,120 |
34,0 | 364 | 220 | 88 | 4 | 4 | 1,740 |
37,0 | 364 | 220 | 88 | 4 | 4 | 2,000 |
