SJ Series Dry-wet Plastic Pelletizing Machine
Specifications
1. Material: PE, PP, PVC waste film
2. Plastic pelletizing machine
3. Competitive price with high quality.
Description:
This machine is suitable for regeneration and granulation of waste plastics, as HDPE,LDPE, and PP, etc. It is equipped with quick motor-operated filter-screen-replacing unit and automatic temperature control. The granulating crusher uses adjustable speed motor, pelletizing with an extruding machine at the same discharging speed synchronistically.
The unit is easy to operate, with a high output, steady performance, and favorable economic benefit.
Main Technical Variables:
Model |
SJ-90 |
SJ-100 |
SJ-110 |
SJ-120 |
Type Diameter of Screw Stem |
φ90 |
φ100 |
φ110 |
φ120 |
Major Diameter Ratio of Screw Stem |
L/D 22:1-25:1 |
L/D 22:1-25:1 |
L/D 22:1-25:1 |
L/D 22:1-25:1 |
Rational Speed of Screw Stem |
10-100r/min |
10-100r/min |
10-100r/min |
10-100r/min |
Main Motor Power |
22kw |
22kw / 30kw |
30kw / 37kw |
37kw / 45kw |
Output |
68kg/h |
95kg/h-110kg/h |
120kg/h-130kg/h |
135kg/h-160kg/h |
Weight of overall(kg) |
2600kg |
2800kg |
3000kg |
3200kg |
Cover dimensions (L×W×H) (mm) |
9000×1500×1800 |
9500×1500×1800 |
9800×1500×1800 |
10000×1500×1800 |
Optional Items:
1- Force feeding for optional
2- Oil hydraulic pump for filter changing for optional
3- Vacuum Suction device for optional.
