Help Center10W Polycrystalline Solar Panels With Full Certificate and High Efficiency
Related Products
-
20W Polycrystalline Solar Panels With High EfficiencyUS$ 0.64 - 0.65MOQ: 5000 Watts -
High Efficiency & Full Certificate 40W Polycrystalline Solar PanelsUS$ 0.64 - 0.65MOQ: 10000 Watts
-
High Efficiency & Full Certificate 50W Polycrystalline Solar PanelsUS$ 0.6 - 0.63MOQ: 10000 Watts
-
60W Polycrystalline Solar Panels With High Efficiency & Full CertificateUS$ 0.6 - 0.63MOQ: 10000 Watts
-
ISO/CE/TUV 70W Polycrystalline Solar Panels With High Efficiency & Full CertificateUS$ 0.58 - 0.6MOQ: 10000 Watts
Polycrystalline Solar panel quality and safety:
1.Rigorous quality control meeting the highest international standards
2.High-transmissivity low-iron tempered glass, strong aluminium frame
3.Using UV-resistant silicon
4.ISO 9001:2008 and ISO 14001:2004
5.IEC61215, IEC61730, Safety Class conformity to CE
Warranty:
5 years for product defects in materials and workmanship
12 years for 90% of warranted minimum power
25 years for 80% of warranted minimum power
Specifications:
ITEM NO.: |
BSM10P |
Maximum Power(W) |
10wp |
Optimum Power Voltage(Vmp) |
17.6v |
Optimum Operatige Current(Imp) |
0.57A |
Open Circuit Voltage(Voc) |
21.2V |
Short Circuit Current(Isc) |
0.68A |
Solar Cell: |
156*156mm Poly |
Number of Cell(pcs) |
4*9 |
Brand Name of Solar Cells |
JA Cell, Bluesun Cell |
Size of Module(mm) |
394mm*267mm*23mm |
Cable & Connector Type |
MC4 |
Frame(Material Corners,etc.) |
Aluminium-alloy |
Backsheet |
TPT |
Weight Per Piece(KG) |
1.1KG |
FF (%) |
70-76% |
Junction Box Type |
Pass the TUV Certificate |
Tolerance Wattage(e.g.+/-5%) |
0~3% |
Front Glass Thikness(mm) |
3.2 |
Temperature Coefficients of Isc(%) |
0.035%/K |
Temperature Coefficients of Voc(%) |
0.351%/K |
Temperature Coefficients of Pm(%) |
0.47%/K |
Temperature Coefficients of Im(%) |
0.04 |
Temperature Coefficients of Vm(%) |
-0.38 |
Temperature Range |
-40°C to +85°C |
Surface Maximum Load Capacity |
2400Pa |
Allowable Hail Load |
23m/s ,7.53g |
Bypass Diode Rating(A) |
10 |
Warranty |
100% of 10 years,80% of 25 years. |
Standard Test Conditions |
AM1.5, 1000W/m², 25 +/-2°C |
Packing |
carton box and pallet |
10W Polycrystalline Solar Panels:
Packing :carton box and outer with pallet.
Normally packing:
1pc/2pcs/3pcs/10pcs/25pcs per carton and can also according to your requirements
Shipment :10 to 15 days after receive deposit or LC
