Mini elecric air conditioner shaded pole motor
1.PRODUCT OVERVIEW
(1) YZ series motors are shaded pole motors with single-phrase and four-poles, and running at the rated voltage/frequency of 220-240V, 50/60HZ or 110-120V, 60HZ.
(2) Shade pole motor are widely applied to radiators, evaporators,condensing unit,ice machine and other refridgration equipments.
(3) Their output power is from 5W to 34W, which can be adjusted according to the stack length.
Model |
Voltage |
Frequency Hz |
Input Power W |
Output Power W |
Current A |
Speed RPM |
Fan Blade mm |
A mm |
B mm |
C mm |
D mm |
E mm |
| YZF5 | 220/240 | 50/60 | 30 | 5 | 0.20 | 1300/1500 | 200 | 13 | 13 | 44 | 79 | / |
| 110/115 | 50/60 | 30 | 5 | 0.40 | 1300/1500 | 200 | 13 | 13 | 44 | 79 | / | |
| YZF7 | 220/240 | 50/60 | 38 | 7 | 0.27 | 1300/1500 | 230 | 19 | 13 | 44 | 85 | / |
| 110/115 | 50/60 | 38 | 7 | 0.54 | 1300/1500 | 230 | 19 | 13 | 44 | 85 | / | |
| YZF10 | 220/240 | 50/60 | 42 | 10 | 0.3 | 1300/1500 | 230 | 19 | 13 | 44 | 85 | / |
| 110/115 | 50/60 | 42 | 10 | 0.6 | 1300/1500 | 230 | 19 | 13 | 44 | 85 | / | |
| YZF16 | 220/240 | 50/60 | 58 | 16 | 0.40 | 1300/1500 | 250 | 25 | 14 | 45 | 92 | / |
| 110/115 | 50/60 | 58 | 16 | 0.8 | 1300/1500 | 250 | 25 | 14 | 45 | 92 | / | |
| YZF18 | 220/240 | 50/60 | 64 | 18 | 0.43 | 1300/1500 | 250 | 30 | 17 | 48 | 100 | 21 |
| 110/115 | 50/60 | 64 | 18 | 0.86 | 1300/1500 | 250 | 30 | 17 | 48 | 100 | 21 | |
| YZF20 | 220/240 | 50/60 | 65 | 20 | 0.47 | 1300/1500 | 250 | 30 | 17 | 48 | 100 | 21 |
| 110/115 | 50/60 | 65 | 20 | 0.94 | 1300/1500 | 250 | 30 | 17 | 48 | 100 | 21 | |
| YZF25 | 220/240 | 50/60 | 100 | 25 | 0.7 | 1300/1500 | 300 | 40 | 18 | 49 | 111 | 31 |
| 110/115 | 50/60 | 100 | 25 | 0.4 | 1300/1500 | 300 | 40 | 18 | 49 | 111 | 31 | |
| YZF34 | 220/240 | 50/60 | 120 | 34 | 0.9 | 1300/1500 | 300 | 45 | 22 | 53 | 120 | 36 |
| 110/115 | 50/60 | 120 | 34 | 1.8 | 1300/1500 | 300 | 45 | 22 | 53 | 120 | 36 |
FENGDA was establish in 1990,covering an area of 17,000 square meters,more than 200 employes.We professionally manufacture various fans and motors,which widely used in Ventilation,air condittion,air condition,cooling and heating industry.
We have gotten CE,UL,CCC certificates and ISO9001 Quality Management System Certification.nd our products are exporting to Europe and America,Middle East,Russia etc.
1. Q: Do you provide warranty for the goods?
2. Q: Could FENGDA provide technology support?
A: We're in this field many years. If there's any problem, please contact with us,we'll provide suggestion from our engineer to help you solve problem.
3. Q: Does FENGDA keep goods in stock or only trading?
A: We have large warehouse for goods. Keep lots of goods in warehouse, so could promise fast delivery.
4. Q: Could you fill the invoice for customs as our requirement?
A: Yes, if there's any requirement for it, please tell us. We'll do it.
1.Warranty:1 year warranty for all products.
2.Products Quality:100% products inspection before delivery.
3.Just in time delivery: Normally,lead time is 30 days.
4.Customized Service: As we have our own molding department,customized service can be provided.
5.Prompt customers services:E-mail will be replied in 24 hours.
