2800mm Width Flatwork/table Cloth Ironing Machine

1.The machine adopts speed-adjusted, users can choose ironing speed according to different fabrics and pressed conditions.

2.Using pressure steam cylinder or infrared quartz tube,to heat drum surface,high heating efficiency.

3.The machine adopts reducer to make the gear running down, with high speed rate, high efficiency over-loading ability and low noise.

4.Using wide conveyer belt for the cylinder adopts rotary connections for sealing to avoid the flowing phenomenon during the period of transmission.

5.The steam input of the cylinder adopts rotary connections for sealing to avoid steam leaking, with longer life.

Type

YPA  I-1800

YPA  I-2500

YPA  I-2800

YPA  II-2500

YPA  II-2800

YPA  II-3000

YPA  III-3000

Tumbler specification(mm)

Φ 800× 1800

Φ 800× 2500

Φ 800× 2800

Φ 800× 2500

Φ 800× 2800

Φ 800× 3000

Φ 800× 3000

Admission hole diameter(mm)

25

25

25

28

32

40

60

Steam consumption

50

70

80

110

150

180

300

Motor Power(Kw)

0.75

0.75

0.75

1.5

1.5

1.5

2.2

Overall dimension(mm)

2800× 1550× 1500

3500× 1550× 1500

3800× 1550× 1500

3550× 2500× 1500

3850× 2500× 1500

4050× 2500× 1500

4050× 3430× 1500

Drum quantity

1

1

1

2

2

2

3

Weight (Kg)

1011

1100

1136

1950

2200

2479

3460
