Specifications
The product supplies16-40 Nm torque could be installed to the Damper, Ventilation window, VAV and other equipmentsTD/TA-16/25/40 Series On-off or Modulating Damper Actuator
TD/TA-16/25/40 Series Damper Actuator is specially designed for the damper control of HVAC system. The product supplies 16-40 Nm torque could be installed to the Damper, Ventilation window, VAV and other equipments directly to adjust the switch, floating and proportion.
Specification & PartNo
Model# |
TDF16/25/40, TA16/25/40 |
Tolerance |
± 10% |
Output Torque |
16 N.m., 25,40 N.m. |
Running Time |
30~150 Sec |
Running Consumption |
6~8VA |
Standstill Consumption |
2~4VA |
Output Angle |
90. (Max 95.) |
|
TDF 3 point and 2 point on/off control |
TA DC(0)2~10 V, DC0(4)~20 mA | |
Shaft Diameter Range |
Φ 14~20 mm or Φ10~14mm |
Overload Protection |
Automatic |
IP Class |
IP54 |
Ambient Temp. Range |
-10~55℃ 0~90%rh |
Max. Noise |
40dB(A) |
N.W. |
1.4~1.9 kg |
Model# |
Torque -N.m. |
Power Supply |
Running Consumption -VA |
Standstill Consumption -VA |
Running time -Sec |
Output Angle Range |
TDF16/25/40-230 |
16/25/40 |
AC230V |
6~8 |
3 |
80~150 |
0~95. |
TDF16/10/40-24 |
16/25/40 |
AC/DC24V |
6~8 |
2 |
80~150 |
0~95. |
TDF16/10/40-120 |
16/25/40 |
AC120V |
6~8 |
3 |
80~150 |
0~95. |
TA16/10/40-230 |
16/25/40 |
AC230V |
6~8 |
3~8 |
80~150 |
0~95. |
TA16/10/40-120 |
16/25/40 |
AC/DC24V |
6~8 |
2~8 |
80~150 |
0~95. |
TA16/10/40-24 |
16/25/40 |
AC120V |
6~8 |
3~8 |
80~150 |
0~95. |
