Home > Products > Rubber machinery > China Best Quality Hydraulic Vulcanizing Press/belt Vulcanizing Press/vulcanized Rubber Machine
China Best Quality Hydraulic Vulcanizing Press/belt Vulcanizing Press/vulcanized Rubber Machine
US$ 2,000 - 30,000
/ Set
1 Set(Min. Order)
- Qingdao
- T/T Credit Card
You May Like
-
China Best Quality Hot Vulcanizing Machine/conveyor Belt Vulcanizing Equipment/plate Vulcanizing Press Machine
-
Factory Direct Sales Manual Vulcanizer/cable Vulcanizing Machine/electric Vulcanizer
-
China Best Quality Shoe Vulcanizing Machine/frame Vulcanizing Machine/conveyor Belt Vulcanizing Process
-
China Best Quality Portable Vulcanizer/vulcanizing Patches/vulcanized Rubber Strips
-
China Best Quality Rubber Tiles Vulcanizing Machine/vulcan Rubber Blanket/vulcanizer for Sale
-
China Best Quality ( Rubber Vulcanizing Agent Required) Plate Vulcanizer/rubber Continuous Vulcanizing Line
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | Baijia | Model Number | XLB-DQ | |
| Voltage | 380V /220V | Power(W) | 2.2KW | |
| Dimension(L*W*H) | 1400*800*1500 | Weight | 3500KG | |
| Certification | ISO9001 CE | Warranty | One year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Reasonalbe pricingHigh quality
Good after sale service
1.Advantage and major usage
Advantage:The plate space and clamping force can be adjusted according your actual requirements ,and machine can equiped with manual-pull mold and automatic hydraulic pull mold , which reduces stuff' workinging strength and inconvenience .
Major usage
a. Plate vulcanizing machine is mainly used for vulcanizing all kinds of rubber and plastic model products,and non-model products.
b.Applicable line:Rubber Sheet, Oil Seal,O Ring,Gasket, Engine Mountings,Hardware Rubber, Molded Rubber Parts and etc.
2.Main Technical Parameter
| Model | XLB-D/Q400*400 | XLB-D/Q550*550 | XLB-D/Q600*600 | XLB-D/Q700*700 | XLB-D/Q800*800 | XLB-D/Q1600*1600 |
| Total Pressure | 0.50MN | 1.00MN | 1.00MN | 1.60MN | 2.00MN | 10.00MN |
| Plate Size(mm) | 400*400 | 550*550 | 600*600 | 700*700 | 800*800 | 1600*1600 |
| Plate Space | 200-400 | 200-400 | 200-500 | 200-500 | 200-500 | 800 |
| Working Layer Number | 1 OR 2 | 1 OR 2 | 1 OR 2 | 1 OR 2 | 1 OR 2 | 1 |
| Piston Diameter(mm) | 200 | 300 | 300 | 360 | 400 | 800 |
| Plate Unit Pressure(Mpa/cm²) | 3.1 | 3.3 | 2.8 | 3.2 | 3.1 | 3.9 |
| Motor Power(kw) | 2.2 | 2.2 | 2.2 | 3 | 3 | 7.5+7.5+11 |
3. Why choose us
a. Quality control system : All the parts are inspected strictly before assemble ,in order to guarantee the machine quality .
b. Strong after sales service team : We pay attention to customers service , we have one strong team specially work for oversea market service.
c. Reasonable pricing : All the machine prices are made according to material cost and market situation , assure customers can get best quality machines at most reasonalbe prices .
4. Some photos of our machines
5. Contact me
Contact Us
- Qingdao Baijia Machinery Co., Ltd.
- Contact nameJessica Nie Chat Now
- Phone86-532-68078147
- AddressWangtai Industrial Park,Jiaonan,Qingdao City, Qingdao, Shandong
