Etching of metal parts
Our customers can avail from us a comprehensive range of Etching Machines, which is widely demanded in various industries. These machines are used to produce PCB's and various metal,glass etching. Fabricated using quality raw material, these machines are known for their high efficiency and sturdy construction and longer service life.
WHOLE VIEW
CHARATERISTICS
I. Imported PP materials, together with toughened glass cover
II. Imported frequency control, pump and electrical components
III. The pressure of each spray pipe is controlled individually and the design of the pipe is slant, which make the spray even, full covered and quickly.
IV. Special design of wheelbase, which is better for producing thin sheet.
V. Man and machine interface
VI. The exhaust and drain design is designed together, which is easy for installation.
VII. The wire is overhead laid, which is convenient for maintenance and avoid liquid medicine.
VIII. Adjustable flow and water-saving design
MAINLY PARAMETER
| Work table width | 630mm |
| Work Height | 900±25mm |
| Convey Speed | 0.2-5m/min |
| Convey Distance | 33mm |
| Application | Max:600mm*any dimesion Min: 600mm*80mm |
| Thickness | Flexible plate≥0.075 Hard plate≥0.8mm |
| Total power | 380V 50HZ 45KW |
| Outline Dimension | 13520mm*1600mm*1280mm |
PROCESS FLOW
LOADING → ETCHING → RECYCLIE WATER WASHING → RUNNING WATER WASHING → DISCHARGE
Application
Metal etching :Copper,Nickle,Zinc ,Aluminum,Iron,Tin,Chrom,Magesium ,Pewter,Brass,Silver,etc.
PCB etching : Mobile PCB, Computer PCB, Light PCB , Battery PCB,etc.
Quality & Inspection
- Cooperated with good reputation suppliers.
- 100% check spare parts quality which produced from matching suppliers.
- QC checking each step from spare parts to production on the full of line.
Production for a series of etching,cleaning, electroplating equipment. At present,we have cooperated with iphone,asus,HP,HTC,Samsung,LG and other industry brand processing manufactures,and we have achieved good reputation.Warmly welcome friends at home and abroad to visit our company and negotiate business.
