0.22 micron nylon pleated cartridge filters used for food and beverage
Specifications:
Filter membrane |
Nylon6 or nylon6 micropore membrane |
Diversion layer |
PP no-woven or screen fabric |
Housing |
PP no-woven |
Inner support |
PP or PP with stainless lining |
OD |
68mm 69mm |
ID |
32mm |
Length |
5~40" |
Seal ring |
Silicon,EPDM,Nitrile,fluorous,fluorous with PTEF |
Precision |
0.10,0.20,0.45,0.65,1.00,3.00µm |
Effective area |
Area≥0.65m² |
PH value |
6~13 |
normal working temperature |
≤60℃ |
Max. working temperature |
85℃,P≤0.10Mpa |
Max.differential pressure |
25℃,forward direction 0.42Mpa,reverse direction 0.21MPa |
Sterilization |
121±2℃ steam for 30min/once or sterile cabinet for 30min/once |
Endotoxin |
<0.25EU/ml |
Extractive |
<0.03g/10"cartridge |
Electronic grade |
Hundred thousand grade purify workshop,18M ultra purify water backwash, which meets with the electronic requirements. |
Pharmacy grade |
Hundred thousand grade purify workshop, purify water backwash, which meets with the GMP standards. |
Food grade |
Hundred thousand grade purify workshop,purify water backwash, which meets withthe FDA safety regulations . |
Water treatment grade |
Purify workshop, sterile air purge. |
2. Mainly characteristics
Nylon membrane( made on steel belt)0.3 times faster than enhanced nylon membrane.
Widely filter precision and selectivity, available for various situations
Adopt fluid dynamics design, high effective
Electrostatic adsorption and micropore filtration.
Ultrasonic welding, without adhesives.
Evenly pore, great mechanical strength
Great ability of removing particles
Oil resistance and organic solvent resistance.
Absolutely precision
Long service life
