Help CenterPolypropylene Pleated Filter Cartridges , 40" 1 Micron Absolute Filter ,water Filter Cartridge
Related Products
-
pp Sediment Filter Cartridge With 5 Micron,Polypropylene Pleated Filter Cartridges ,40 Inch Water Filter CartridgeUS$ 1 - 2MOQ: 20 Pieces -
Polypropylene Pleated Filter Cartridges ,pp Filter Cartridge ,water Filter CartridgeUS$ 2 - 3MOQ: 10 Pieces
-
High Quality PP Pleated Filter Cartridge ,water Cartridge Filter for FiltersUS$ 0.1 - 2MOQ: 10 Pieces
-
High Filtration Efficiency Pleated PP Filter Cartridges/5 Micron PP Filter Element/sterile Filter for Pharmaceutical IndustryUS$ 1 - 2MOQ: 10 Pieces
-
5 Micron Rating 40 Inch Pleated PP Filter Cartridge /water Filter Replacement/water Filter CartridgesUS$ 1 - 2MOQ: 10 Pieces
Material Of Construction | Filter media | Polypropylene |
| Support Layers | Polypropylene |
| Micron rating | 0.1,0.2,0.45,0.65,1.0,2.0,3.0,5.0,10,30,50,70,100 μm |
| Inner core | Polypropylene |
| Outer cage,End Cap | Polypropylene |
| Seal Method | Thermal Bonded,No Adhesives |
| O-ring/Gaskets | EPDM,Slicone,Buna,Viton |
Cartridge Dimensions | Outer Diameter | 69mm(2.75”) |
| Inner Diameter | 28mm(1.10”) |
| Length(Based on DOE End Cap) | 10”-254mm,20”-508mm,30”-762mm,40”-1016mm |
| Filtration Area(m2) | 0.65m2 per 10” |
Operating Conditions | Normal Operating Temperature | Up to 65℃ (140℉) |
| Max.Operating Temperature | 90℃ (194℉) at P≤1.0 bar (14.5psi) |
| Forward Flow Direction | 4.2 bar (60 psi) at 25℃ (77℉) |
| Reverse Flow Direction | 2.1 bar (30psi) at 25℃ (77℉). |
| PH Value Compatibility | 1-14 |
| Sterilization Temperature Time | Steam Sterilization for 30 minutes at 121±2 ℃, 100 cycles, Autoclave 30minutes (optional)
|
Cartridge Safety | Endotoxin | <0.25 EU/ml |
| Extractables | 0.03g / 10" |
Q1. Can I have a sample order for filter cartridge?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A:Sample needs 3-5 days, mass production time needs 1-2 weeks after the payment.
Q3. Do you have any MOQ limit for filter cartridge?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for filter cartridge?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on filter cartridge product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
