LR-1007-120W12V DC ITX POWER

LR-1007-120W12V DC ITX POWER thumbnail-1
LR-1007-120W12V DC ITX POWER thumbnail-2
LR-1007-120W12V DC ITX POWER thumbnail-3
LR-1007-120W12V DC ITX POWER photo-1
LR-1007-120W12V DC ITX POWER photo-2
LR-1007-120W12V DC ITX POWER photo-3
US$ 7 - 12 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
realan
Model Number:
LR-1007
Contact Supplier Request Quote Chat Now
Shenzhen Realan Computer Products Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name realan
Model Number LR-1007
Output Voltage 12v
Output Frequency 50w
Output Current 8A



INPUT VOLTAGE RANGE:11.2VDC—14.8VDC



INCOMING CURRENT RANGE:12.0A Max @11.2VDC



INPUT SURGING CURRENT:12.0Vmax@12VDC



WORK EFFICIENCY:≥85%







         OUTPUTREQUIRED: FIVE GROUPS OF POWER OUTPUT                                       TESTING EMPHASIS



Item

Output voltage

Output current(A)

min(V)

avg(V)

max(V)

ripplewave(mV)

Sb current

avg

peak

+3.30V

+3.14

+3.30

+3.47

50

0

6.0

8.0

+5.00VSB

+4.75

+5.00

+5.25

50

0.1

1.6

2.0

+5.00V

+4.75

+5.00

+5.25

50

0

6.0

8.0

+12.00V

+11.20

12.00

+12.8

120

0

4.0

4.5

-12.00V

+10.80

-12.00

-13.20

120

0

0.1

0.15





      Input/output interface









INPUT                                                                                  OUTPUT





         Defencive fuction  (for+3.3V,+12V,+5.00V&+5.00VSB power output)



OCP: output shut down when output current reaches the peak point.



Short-circuit protection:output shut down when short-circuit.









      PSU timing sequence:













     Environment description:



Working temperature/humidity       15°C to 35°C / 45%-75%



Reposition temperature//humidity   -40°C to +70°C/ 10%-90%



Atmospheric pressure            86Kpa—106Kp







      Other parameters:



Working frequency:Icbuilt-in oscillator(250-350)kHz@Vcc=12V











Feedback reference voltage:0.8V±2%@12VDC















      Design drawing:



TOP











BOTTOM









SILKSCREEN  TOP











PRODUCT OUTLINE DRAWING
