FSM Submersible Dewatering Pump FSM2.75(F)
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Model Number:
FSM
Theory:
Centrifugal Pump
Structure:
Single-stage Pump
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SH Submersible Drainage Pump SH422 / SH630NegotiableMOQ: 1 -
Single-stage and Dual-stage Vacuum PumpNegotiableMOQ: 1
-
Inline PumpNegotiableMOQ: 1
-
Self-Priming Trash Pump SP-4 4" x 4" Trash Self-Priming PumpNegotiableMOQ: 1
-
Self-Priming Trash Pump SP-6 6" x 6" Trash Self-Priming PumpNegotiableMOQ: 1
Model Number
FSM
Theory
Centrifugal Pump
Structure
Single-stage Pump
Usage
Water
Power
Electric
Standard or Nonstandard
Standard
Pressure
Low Pressure
Specifications
1. CE Certificate2. 100% Copper Wire
3. Semi Vortex impeller
4. Built-in shaft
Description:
- Semi vortex impeller design minimize the clogging situation for maximum durability and maintaining pump performance.
- Built-in shaft mounted agitator prevent the air lock and reduce the clogging situation.
Features:
- The large channel in the spiral casing allows the high sand and slit content water to pass through easily.
- The shaft-mounted agitator prevents the air lock that tends to take place on vortex pumps.
- The pump section can be disassembled and reassembled using a single 13-mm bax wrench.
Application:
- Civil engineering.
- Building sites or utility pits, drainage storm water, groundwater.
Specification:
- Starting method: capacitor run
- PH: 6.5 to 8.5
- Insulation Class: F IP168
- Cable: Length 8mm
- Water temperature: up to 40°C
- Max. water depth: 10m
| Model | FSM2.75(F) |
| Outlet | 50 |
| Power | 0.75KW |
| Max. Head | 18m |
| Max. Capacity | 0.3m³/min |
| Impeller Passage | 9mm |
| Net Weight (KG) | 16 Kilogram (KG) |
| Gain Weight (KG) | 17 Kilogram (KG) |
| Packing Size (MM) | 250mm*210mm*430mm |
