Diesel Trash Pump WP-30DT
Negotiable
1 (Min.Order)
- 0 per Month
You May Like
- MONO progressive block for prefabried concrete houses
- MONO progressive block for concrete pump spare parts
- MONO progressive block for ready mix concrete trucks
- MONO progressive block for concrete statue molds
- MONO progressive block for concrete columns mold
- MONO progressive block for gearbox for concrete mixer
Product Details
Brand Name: | SHARK | Model Number: | WP-30DT | Theory: | Other, self priming pump |
Usage: | Other, trast pump | Power: | Electric | Standard or Nonstandard: | Standard |
Fuel: | Diesel | Pressure: | High Pressure |
Product Description
Specifications
3" Diesel Water Pump powered by 4-stroke diesel engine
Diesel Trash Pump WP-30DT:
Features:
3" Diesel Water Pump powered by 4-stroke diesel engine.
High output trash pumps, capable of handling granule up to 1.25" diameter.
Removable front cover for easy cleaning and maintenance.
Highly effective mechanical seal.
Compact in structure and light in weight.
Aluminum alloy high pressure casting.
Specification:
Suction & Discharge Port Dia. (mm) | 80(3.0) |
Max. Head(m) | 26 |
Max. Suction(m) | 8 |
Max. Flow(M³/H) | 78 |
Max. hard matter(mm) | 35 |
Self Priming Time (s/4m) | 120 |
Model | SH178F |
Type | Forced air-cooled, 4-stroke, Diesel |
Displacement (cc) | 296 |
Max Output (Hp/rpm) | 6,0/3600 |
Fuel | Diesel |
Fuel Tank Capacity (L) | 3,5 |
Oil | SAE10W30 (Above CC Grade) |
Oil Capacity (L) | 1,1 |
Ignition System | Direct injection |
Starting System | Recoil |
Net Dimension (LxWxH(mm)) | 605x480x550 |
Overall Dimension (LxWxH(mm)) | 620x495x570 |
N.W / G.W (kg) | 56/58 |
