good quality Drum Separator for wheat cleaning

Specifications

1. Sturdy Construction
2. Convenient Maintenance
3. Reasonable Design
4. Low Noise



2014 New design low price hebei pingle maize starch

production plant

Product Description

1. Display:

Intake Section — Silo— First Cleaning Section—Conditioning Silo

—Second Cleaning Section— Milling Section— Packing Section







2. Features of hebei pingle maize starch production plant :



1) High efficiency cleaning equipment, including aspiration seperator, vibro sparator,destoner,

dempener,disc cylinder selector.

2)Advanced milling equipment, including pneumatic control roller mill, electric control roller mill,

square plansifter, purifier.

3) High precision packing machine from 5kg to 50kg.



3. Pictures for client reference:







4.Specifications:

Drum Separator

The TSCY drum separator is a universal grain pre-cleaning device that is commonly seen in grain mills, feed manufacturing plants and many other industries. The round screening drum rotates continuously to effectively remove coarse and fine impurities from grains, such as stones, bricks, ropes, wood chips, soil blocks, pieces of straw, etc. In this way, the downstream processing and conveying machines are well protected from being blocked or damaged.

Features1. The screening drum has a horizontal arm, and this drum is divided into an inlet cylinder and an outlet cylinder that have different hole sizes. So, the separation efficiency is extremely high. For example, at least 99 percent of coarse impurities are removed from the original grain with the help of this drum separator.

2. The backward feeding method is applied, and the discharge part is equipped with a spiral to prolong the actual processing length, thus improving the final result. Moreover, plump grains won't be mistakenly classified into coarse impurities and discharged with the impurities.

3. During screening, fiber and straw are in a bulk shape and are directed to the outlet by a guide screw. There is a scraper brush inside the drum, and it could clean the impurities in a reliable and automatic way. In addition, it is very convenient to change the screen or implement maintenance work.

4. This drum separator has a compact structure, and the low power running cuts down the operation cost to a large extent.

Technical Parameters

Model	TSCY63	TSCY80
Drum diameter (mm)	630	800
Drum length (mm)	840	950
Drum speed (r/min)	23	18
Air requirement (m 3 /h)	640	720
Motor power (kW)	0.55	0.75
Throughput (t/h)	10-15	25-30
Overall dimensions (L×W×H, mm)	1780×880×1260	2080×1000×1440

6.More products for you to choose:

















Company Information

1.About us

     Professional manufacturer specialized in grain processing project manufacturing

and installation with more than 20 years experience.Main products includes wheat

flour milling machine and maize milling machine. Our products have been exported

to 32 countries and regions such as Egypt, Ethiopia, India, Iran, Vietnam, Brazil etc.

The international Trade Division sets up sales dep., technical engineer dep., after sales

service dep.and documentation and logistical dep., which can manage engineer designing,

installation and service with professional staff.
