Home > Products > PCB Punching Machine > FPC manual punching machine
FPC manual punching machine
- 100 Set / Sets per Month
- Shenzhen Shanghai ningbo
- T/T L/C D/P D/A Credit Card PayPal
Product Details
CNC or Not: | Yes | Cooling Mode: | Air Cooling | ||
Brand Name: | YUSH | Model Number: | YSPE | Certification: | CE, CE |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
FPC manual punching machine - YSPE
Feature:
1.Apply to cut Rigid pcb,Flexible pcb(FPC),Rigid-Flexible pcb.
2,Use punching mould to cut with high efficiency.
3.Can replace multiple mold for production and mold changing easily.
4.The operation is simple and safe.
Specifications:
Model | YSPE |
Punch Contribute (T) | 3 (can custom made up to 30T) |
Working area (mm) | 330*220 (can custom made) |
Voltage(V) | 110/220 |
Working air pressure(Mpa) | 0.5-0.7 |
PCB punching tool size (mm) | 730*810*1700 |
PCB punching tool weight (kg) | 530 |
Feature:
1.Machine has strong structure and moves easily with 4 Casters.
2.can replace a variety of mold, and mold changing easily.
3.the lower mold automatic in and out, easy to pick and place products, finished products can fall into the drawer.
4.make internal stress generated by PCB cutting to minimize and avoid tin stress cracking.
5.punching cutting semi-finished PCB with high efficiency.
6.mould and die can be made according to customer's request.
