PCB punching machine
YSV-1M
Aluminum PCB punching machine Detailed Product Description
PCB depaneling economical type
1.PCB Protection
2.Calibration Blade Setting
3.All Speed Control By Human
4.More Accurating
Aluminum PCB punching machine Specification:
Model |
YSV-1M |
PCB Cutting Length (mm) |
460/700 |
Cutting Speed (mm/s) |
manual |
Cutting Thickness (mm) |
0.6~3.5 |
Size (mm) |
400*780*480 / 1220*560*650 |
Weight (Kg) |
55 / 80 |
Blade working life for metal (Year) |
0.5 |
Blade working life for PCB (Year) |
1 |
Guarantee (Year) |
1 |
Delivery (Day) |
1 |
V-CUT Aluminum PCB punching machine Detailed Product Description
1. For electronics, cell phones, computers, PCB, FPC (flexible printed circuit board),LED.
2. Mold make of SKH-11 Steel, Blade is SKH-9(From Japan), rigorous Job!!!! Dedicated
to high strength cutting, and excellent toughness, able to cut metal board !!!!!!
Aluminum PCB punching machine Technical characteristics:
1. Structural precision, the load evenly, to eliminate internal stress
2. Safe, easy to operate
3. For electronics, cell phones, computers, PCB, FPC (flexible printed circuit board)
Aluminum PCB punching machine Feature:
1.Round knife, manually cutting against lower linear knife, for reduced stress
2.Separate pre-scored PCB assembly without stress on either PCB or component
3.One touch programming of cut length with digital display
4.Separating speed is adjusted by a rotary knob
5.Handle Intermittent scoring or cut-outs
6.Board with projected component can be cut precisely
7.Large stainless steel platform on both side of cutting blade prevents board wobble and table height and angle are adjustable
8.Optional PCB conveyor belt to remove finished board
9.Clearance between circular and linear blades are adjustable to fit different groove depth and compensates for blade wear out
Aluminum PCB punching machine Advantage :
1.Pcb depanelizer original manufacturers, price concessions
2.Promise day technical support services
3.Limit the handling of complaints, half an hour back to customers
4.Depanel Experts, the provision of professional PCB sub-programme
5.Reliable machine maker,we get Experts--15,each one got over 6 years
experience,equipment quality will be satisfying.
