Great Wall China Top Level Gravel Plants

Specifications

China Top Level Gravel Plants
1. Small amplitude
2. High efficiency top quality
3. Long service life
4. Low investment cost.

"Great Wall Make Great Machine"



Different Colors&Packages are available













Other HOTEST MODELS For View

















ISO9001:2008 Approved,For test report details,pls contact "GreatWall"







The Vibrating Screen Sieve moves round with multi-layers and high efficiency. It can screen materials into multiple levels products according to different sizes. The Vibrating Sieve Machine is widely used for grading and screening in fields of mining, building material, transportation, energy,chemical industry, etc.



II. Working Principle
The motor drives the vibrator via v-belt, which makes the screen do a cyclical reciprocating in the directin of vibrator.  The materials are sieved by making round movement in the screen.



III. Features

Long flowing line and various screening specifications.
Using the eccentric blocks to generate strong vibrating force.
Screen cross-beam and box are connected by strong belts, simple structure, convenient in maintenance.
Small amplitude, high frequency, large-inclination structure, high efficiency, large capacity, long service life, low power consumption and noise.



IV. Main Specifications





Model	Screen Size (mm)	Screen Decks	Screen Hole Size (mm)	Max. Feeding Size (mm)	Capacity (t/h)	Motor Power (kw)	Weight (t)	Overall Dimension (mm)
2YZS1237	3700×1200	2	3-50	200	10-80	11	2.40	4773×2050×2247
3YZS1237	3700×1200	3	3-50	200	10-80	11	3.05	4773×2050×2700
2YZS1548	4800×1500	2	3-100	400	30-200	15	5.35	5900×2270×1620
3YZS1548	4800×1500	3	3-100	400	30-200	15	6.07	5900×2270×1670
2YZS1848	4800×1800	2	3-100	400	50-280	18.5	6.15	5900×2560×1620
3YZS1848	4800×1800	3	3-100	400	50-280	18.5	6.93	5900×2560×1670
2YZS1860	6000×1800	2	3-100	400	65-550	22	6.95	7060×2560×1620
3YZS1860	6000×1800	3	3-100	400	65-550	22	7.70	7060×2560×1670
4YZS1860	6000×1800	4	3-100	400	65-550	30	8.70	7060×2560×1930
2YZS2160	6000×2100	2	3-100	400	81-720	22	8.48	7130×2990×1760
3YZS2160	6000×2100	3	3-100	400	81-720	30	9.24	7130×2990×1810
4YZS2160	6000×2100	4	3-100	400	81-720	30	10.45	7130×2990×1930
2YZS2460	6000×2400	2	3-150	400	100-810	30	12.35	7130×4121×1810
3YZS2460	6000×2400	3	3-150	400	100-810	37	13.85	7130×4121×1940
4YZS2460	6000×2400	4	3-150	400	100-810	37	15.60	7130×4121×2080















Services:

1.Pre-sales Service
 Offering comprehensive technical and business consultation services;
  Proposing th e most suitable scheme and equipment for our clients;

  Designing and fabricating targeted products according to the special requirements of clients;
  Training periodically high qualified service technician.

2.After-sales Service
  Highly inspecting equipments in every working procedure, quality comes first;
  Fast & Safe Delivery;
  Assisting our clients for foundation construction of equipments;
  Dispatching engineers to install and debug equipments;
  Training the first-line operators on site;
  Regularly visit clients to solve production problems;
  Providing life-long maintenance service;
  Providing technical exchanging;













About Us:

With more than twenty years' history, Zhengzhou Great Wall Heavy Industry Machinery Co.,Ltd. is a manufacture which specialized in R&D, manufacturing and selling big and middle size heavy industry machinery. Since establishment, we make a good image in the market with scientific management, qualified products and perfect service.



Our main products are crushers, grinding mills, other equipments for crushing plant and grinding plant, as well as building construction equipments. They are widely used in mining, building material, metallurgy, chemical, traffic, reservoir and so on. Our products are not only sold well in more than twenty provinces and cities in China, but also in tens of countries and regions in Eastern Europe, Middle East, Asia, Africa, North America, South America, and Oceania.



Now we have domestic top ranking production equipments and precise testing instrument, each process of products is strictly inspected to guarantee the products to achieving high ex-factory standard. Besides, we cooperate with many famous universities and scientific research institutions, so that can make technical warrantee for the products in it's developing, updating and improving.



"persons of ability guarantee the quality". Our company takes in persons of ability and gives training to the staffs annually to their quality and skill to meet the development of the company.



With the right of importing and exporting, the company owns an international trading department which is specialized in sales and exports, we provide the best service to the foreign clients.



During the past years, we stick to "honest, truth-seeking, innovation and hard working". To keep "Great Wall" brand, we will improve ourselves and try our best to make perfect products and the best service.

































Do not hesitate send us inquiry for more details about the China Top Level Gravel Plants  .
