1.6KW Inverter Generator IN1800 --Tiger Manufacturer
US$ 245 - 260
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
Tiger /OEM
Model Number:
IN1800i
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Silent Inverter Generator 2kw (since 1995)US$ 285 - 300MOQ: 10 Pieces -
2kw Gasoline Digital Inverter Generator IN2500iUS$ 280 - 295MOQ: 10 Pieces
-
Digital Inverter Generator 1.6KW IN1800i - TigerUS$ 240 - 249MOQ: 300 Pieces
-
Digital Inverter Generator 0.8KW IN800i - TigerUS$ 175 - 182MOQ: 520 Pieces
-
PM-T Inverter Generator 5KW,5.5KW INF6800 - TigerUS$ 580 - 600MOQ: 10 Pieces
Place of Origin
Jiangsu, China
Brand Name
Tiger /OEM
Model Number
IN1800i
Output Type
Other, Inverter
Speed
3000~4500rpm
Frequency
50Hz
Rated Power
1600W
Rated Voltage
230V
Rated Current
7.2A
Specifications
Inverter generator in lightweight portable electricity. Easy to Carry , Lower engine speed. Reduced noise, fuel consumption etc|
Inverter generator IN1800 GENERAL FEATURES |
||||
| Voltage: | 230 | |||
| Maximum power LTP | ||||
| Prime power PRP: | ||||
| Continuous power COP: | ||||
| Nominal Current: | 7 | |||
| Power factor: | 1 | |||
| Voltage: | 230 | |||
| Frequency: | 50 | |||
| Phases: | SIN WAVE | |||
| Battery charger: | High idle/Low idle: 1015V/1520V | |||
| Referring conditions as DIN6271, altitude 100 m above sea level, temperature 27°C, humidity 60%. | ||||
| ENGINE | ||||
| Model: | TGF100 | |||
| Stroke: | 37.6 | mm | ||
| Cylinder bore | φ58 | mm | ||
| Fuel | UNLEADED GASOLINE #93 | |||
| Number and disposition of cylinders | Single | |||
| Displacement: | 99.3 | cc | ||
| Air intake: | Natural Aspiration | |||
| Starting system: | Manual Starting | |||
| Speed: | 3000-4500 | rpm | ||
| Continuous power: | 1600 | W | ||
| Maximum power: | 1800 | W | ||
| Oil capacity: | 0.5 | L | ||
| Fuel consumption full load: | 1.5 | L/h | ||
| Electric system voltage: | N.A | Volt | ||
| Oil deficiency shut-down | YES | |||
| Fuel tank capacity: | 3 | L | ||
| Running time full load: | 2 | h | ||
| Accoustic pressure level at 7 m: | 72 | dB(A) | ||
| Guaranteed sound power level (2000/14/EC): | 94 | dB(A) | ||
| Product data / Product group: Portable Gensets | ||||
| Product name | Gasoline Inverter Generator | |||
| Model | IN1800 | |||
| ALTERNATOR: | ||||
| Model: | IN1800 | |||
| Poles: | 21 | |||
| Alternator Typ: | Permanent Magnet Alternator | |||
| Typ of protection | CLASS F | IP23 | ||
| Speed: | 30004500 | rpm | ||
| Voltage: | 230 | Volt | ||
| Frequency | 50 | Hz | ||
| Continuous power: | 1600 | W | ||
| Power factor: | 1 | Cosfi | ||
| Active continuous power: | 1600 | W | ||
| Efficiency full load: | 100 | % | ||
| Maximum admitted overload: | 1800 | W | ||
| Voltage regulation system: | Closed Cycle Control | |||
| Protective switch | Electronic Overload Protection | |||
| OVERALL DIMENSIONS AND WEIGHT | ||||
| Weight without packing: | 21.5 | kg | ||
| Weight incl. packing: | 23.5 | kg | ||
| Dimensions: | LXWXH | 530×285×450 | mm | |
| Dimensions packing: LXWXH | 560 X 301 X 478 | mm | ||
| OUTFIT | ||||
| Number of Sockets | 230 V 16 A | |||
| Number of Sockets | CEE 230 V 16 A | |||
| Number of Sockets | CEE 230 V 32 A | |||
| Number of Sockets | CEE 400 V 16 A | |||
| Number of Sockets | CEE 400 V 32 A | |||
| Number of Sockets | 12 V | |||
| Other Equipment | ||||
| No | ||||
| Available accessories | ||||
| Convential tool-kit(spark wrench, spanner, manual ) | ||||
| 1Double-head Screwdriver | ||||
| 2Spark plug socket spanner | ||||
| 38-10 socket spanner | ||||
| Certificates / Tests | ||||
| CE-Declaration of conformity | ||||
| VCA Emission test Under ROAD TRAFFIC ACT 1988-SECTION 80 | ||||
| EPA | ||||
| CETL | ||||
