Help CenterLow Frequency 10dB Directional Coupler 400-450MHz
Related Products
Specifications
low frequency Directional coupler1. We are Manufacturer of RF directional coupler
2. wide frequency ,low insertion loss
Techanical Specification of low frequency Directional coupler :
Product Name |
low frequency Directional coupler |
Model |
YFTX-DC-445-10-NF |
Frequency(MHz) |
400-450MHz |
Coupling(dB) |
10±0.8 |
Insertion Loss(dB) |
0.8 |
Isolation(dB) |
≥20 |
VSWR |
≤1.25:1 |
PIM3 |
≤-120dBc |
Power Capacity(W) |
200 |
RF Connector |
N-female |
Impedance(ohm) |
50 |
Relative Humidity |
5%-95% |
Color |
Black-plated |
Temperature(deg) |
-35~+80 |
Noted: All the specifications can be changed as Customer's request.
Details view for low frequency Directional coupler :
Packing Details for low frequency Directional coupler :
each piece in opp bag, each bag in small white inner box, and then the small boxes in standard exporting carton. the products will be protected very well with paper cardboard and foam
.
