thermal insulation waterproof material
- 1000 Ton / Tons per Month
- China port
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Application: | Refractory | Thickness: | 10-80mm | Width: | 1000/700/600 Mm |
Length: | 600/900/1000/1200mm | Grade: | COM (Common) | Chemical Composition: | AL2O3+SIO2 |
Working Temperature: | 1000-1800 | Fiber Diameter: | 3-5um | Thermal Conductivity: | 0.135 |
Shrinkage (1800℉, 3h): | 1.1 | Place of Origin: | Henan, China | Model Number: | 1260 STD |
Brand Name: | hengrui |
Product Description
Hengrui thermal insulation waterproof material is made by using Hengrui ceramic fiber bulk and a little binding agent through vacuum forming. Hengrui ceramic fiber board can maintain its mechanical strength after high-temperature heating, and the board includes 6 levels: 1050℃, 1260℃, 1350℃, 1430℃, 1600℃, and 1700℃. Hengrui ceramic fiber board can resist the scouring of airflow for its high strength, so it can be the material of internal linings.
The usability of thermal insulation waterproof material is really good under the condition of high moisture. Hengrui ceramic fiber board has excellent hyd-rophobicity after processing by specific techniques.
Hengrui thermal insulation waterproof material is made by using Hengrui ceramic fiber bulk and inorganic binding agent through vacuum forming. When using the board under the circumstance of high temperature, the pollution gas will not be generated.
◊Back-up lining of high-temperature industry furnaces.
◊Hot-face lining of ceramic kilns, heat-treatment furnaces and other industrial kilns.
◊Back-up and hot-face insulation materials for furnaces or aluminum industry.
◊Insulation material of Metallurgy,Machinery,Chemical,Optical,and environmental protection industries.
◊Precise size and smooth surface.
◊Easy to cut and install, and convenient to construct.
◊Low impurity content; identical bulk density and thickness.
◊Excellent mechanical and structural strength.
◊Low thermal conductivity and low shrinkage.
◊Ability to resist the scouring of airflow.
thermal insulation waterproof material | HR1050
| HR1260ST
| HR1260HP
|
HR1350HA
| HR1430Zr
| HR1600 PMF
| HR1700 PMF | |
Classification Temperature(°C)
| 1050 | 1260 | 1260 | 1350 | 1430 | 1600 | 1700 | |
Density(KG/M3)
| 250-350 | 250-350 | 250-350 | 320-400 | 320-400 | 400-550 | 400-550 | |
Linear shrinkage%(24h) | ≤2.0 900°C | ≤2.0 1000°C | ≤2.0 1000°C | ≤2.5 1100°C | ≤3.0 1200°C | ≤1.5 1400°C | ≤1.5 1500°C | |
Flexural strength(MPa)
| ≥0.5 | ≥0.5 | ≥0.5 | ≥0.5 | ≥0.5 | ≥0.7 | ≥0.7 | |
Thermal conductivity rate(W/m.k) | 400 °C | 0.08 | 0.084 | 0.084 | 0.084 | 0.084 | -- | -- |
600°C
| 0.11 | 0.128 | 0.128 | 0.125 | 0.125 | 0.16 | 0.16 | |
Chemical Composition(%) | Al2O3
| 42-44 | 45-46 | 47-49 | 52-55 | 38-44 | ≥72 | ≥75 |
Al2O3+SiO2
| ≥99.0 | ≥99.0 | ≥99.0 | ≥99.0 | ≥83 | ≥99.0 | ≥99.0 | |
ZrO3 | - | - | - | - | 15-17 | - | - | |
Other | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 | ≤1 |
We can do OEM for trading company
