TS008A Mixing Yarn Winder

TS008A Mixing Yarn Winder photo-1
TS008A Mixing Yarn Winder photo-2
TS008A Mixing Yarn Winder photo-3
TS008A Mixing Yarn Winder photo-4
TS008A Mixing Yarn Winder photo-5
US$ 15,000 - 35,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
mixing yarn winding
Type:
Winder Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application mixing yarn winding
Type Winder Machine
Production Capacity 300-500M/min
Place of Origin Jiangsu, China
Brand Name TANGSHI
Model Number TS008A
Automatic Other, Semi-auto
Dimension(L*W*H) 13500 x 1000 x 1600 mm
Weight 3000kg
Power(W) 0.18kw per spindle

Specifications

TS008A Mixing Yarn Winder, can mixing winding 2-6 plys yarns together on the bobbin.

 TS008A Mixing Yarn Winder



TS008A Mixing Yarn Winder



TS008A Mixing Yarn Winder



TS008A Mixing Yarn Winder

TS008A Mixing Yarn Winder



Machine Application:
  TS008A Multi-ply Mixing Yarn Winder Machine, it's for multi ply yarns mixing winding together, can wind like 2-12 plys yarns on the bobbin, can suit like cotton yarn, wool yarn, fiber yarn, polyester yarn and etc.

Feature:

1. Master digital controller;

2. each spindle run separately with a motor drive;

3. Length counter installed on each spindle;

4. Auto stop device;

5. adjust speed by inverter;

6. uniform tensioner;

Technical parameters:

Spindle No.

Max 36 spindles

Spindle Gauge

420MM

Spindle NO. per group

4 spindles

Winding yarn Plys

2-12 plys

Winding Speed

≤500m/min

Driver:

Each spindle with a motor driving

Tensioner:

tabletting tension

Auto Stop Device

Yarn sensor

Traverse Gauge

6-10' inch

Air Splicer

Optional installed

Blower cleaner

Optional installed

Brake system

Optional installed

Dimensions

L 1920 x W 850 x H 1600 mm (one group size)
