TS008A Thread Mixing Machine

Name: TS008A Thread Mixing Machine
Brand: TANGSHI
SKU: 132964455
Availability: InStock

TS008A Thread Mixing Machine thumbnail-1

TS008A Thread Mixing Machine thumbnail-2

TS008A Thread Mixing Machine thumbnail-3

TS008A Thread Mixing Machine thumbnail-4

US$ 15,000 - 35,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Application:

mixing yarn winding

Type:

Winder Machine

Contact Supplier Request Quote Chat Now

Xinghua Tangshi Textile Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Application mixing yarn winding

Type Winder Machine

Production Capacity 300-500M/min

Place of Origin Jiangsu, China

Brand Name TANGSHI

Model Number TS008A

Automatic Other, Semi-auto

Dimension(L*W*H) 13500 x 1000 x 1600 mm

Weight 3000kg

Power(W) 0.18kw per spindle

Specifications

TS008A Multi-ply yarns mixing winding machine, for mixing winding 2-6 plys yarns together on the bobbin.

Machine Application:
TS008A Multi-ply Yarns Winder Machine, it's for multi ply yarns mixing winding together, can wind like 2-12 plys yarns on the bobbin, can suit like cotton yarn, wool yarn, fiber yarn, polyester yarn and etc.

Feature:

1. Master digital controller;

2. each spindle run separately with a motor drive;

3. Length counter installed on each spindle;

4. Auto stop device;

5. adjust speed by inverter;

6. uniform tensioner;

Technical parameters:

Spindle No.	Max 36 spindles
Spindle Gauge	420MM
Spindle NO. per group	4 spindles
Winding yarn Plys	2-12 plys
Winding Speed	≤500m/min
Driver:	Each spindle with a motor driving
Tensioner:	tabletting tension
Auto Stop Device	Yarn sensor
Traverse Gauge	6-10' inch
Air Splicer	Optional installed
Blower cleaner	Optional installed
Brake system	Optional installed
Dimensions	L 1920 x W 850 x H 1600 mm (one group size)
