DS-010 Push Button Switch With Wire and Symbole Logo
Negotiable
MOQ: 5000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
WANSHFA
Model Number:
DS-010
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PBS-GQ19D/L Metal 5A Push Button Switch IP65NegotiableMOQ: 5000 Pieces -
PBS-GQ19XD 12v Indicator Push Button SwitchNegotiableMOQ: 5000 Pieces
-
PBS-2BA31 Even Push Button SwitchNegotiableMOQ: 5000 Pieces
-
LA156 LED Push Button SwitchNegotiableMOQ: 5000 Pieces
-
25mm Round Lighted Push Button SwitchNegotiableMOQ: 5000 Pieces
Place of Origin
Zhejiang, China
Brand Name
WANSHFA
Model Number
DS-010
Protection Level
IP 65,66
Max. Current
3a
Max. Voltage
250V
Specifications
DS-010 Push Button Switch with wire and symbol logo1.with logo
2.IP65,66
3.Service Life 100,000 Cycles
4.CE,CCC,ISO9001
DS-010 Push Button Switch with wire and symbole logo
Description:
15 years' experience of manufacturing in this field.
External AppearanceVisual measurement: surface of metals cleanness, no rust stain, no cladding shell off
Temperature-25~ +70°C
Relative Humidity( 40°C) ≤ 95%
Normal Load 1A AC 250V
Withstand VoltageAC250V (50Hz)/1min
Travel 4mm
Service Life 100,000 Cycles
Operating Force 4N
Center Distance2.2mm
Diameter7mm
Height21.4mm
Length of Terminal 5.1mm
Width of Terminal 0.5mm
Quantity of Terminals 2
Setup ModeVertical Plug-in
UsesInstrument,Meter,Household Appliances
Specification:
| Rating | 1A 250V 3A 125VAC |
| Contact resistance |
≤50mΩ |
| Insulation resistance | ≥100mΩ |
| Withstand voltage | 500VAC |
| Switching life | ≥10000cycles |
Contour:
