Help CenterKW11-3Z Mini Push Button Micro Switch
Negotiable
MOQ: 1000 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
WANSHFA
Model Number:
KW11-3Z
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
KW11-3Z Mini Waterproof Types of Micro SwitchNegotiableMOQ: 1000 Pieces -
KW11-3Z 10a 125vac Micro SwitchNegotiableMOQ: 1000 Pieces
-
KW11-3Z Snap Action Micro Switch 250vacNegotiableMOQ: 1000 Pieces
-
KW11-3Z 10a Push Button Micro SwitchNegotiableMOQ: 1000 Pieces
-
KW3 5a Micro Switch 250vacNegotiableMOQ: 1000 Pieces
Place of Origin
Zhejiang, China
Brand Name
WANSHFA
Model Number
KW11-3Z
Max. Current
10a
Max. Voltage
250V
Operating Temperature
-20~80
Protection Level
IP65
Specifications
KW11-3Z mini push button micro switch1.In :5A,250VAC;10A 125VAC
2.10A 125VAC/5E4
3.button micro switch
4.CCC,CE,TUV,ISO
KW11-3Z mini push button micro switch
15 years' experience of manufacturing in this field.
Nice appearance,tight configuration.
Characteristic:small contact clearance.
Quick action,high sensitivity and small operating travel.
Long life,high reliability.
A variety of models with low operating force to high operating force are available.
Push button type micro switch.
Specification:
| Rating | 5A125/250VACT125 5A250VAC5E4 5A250VAC 10A125VAC/10A250VAC |
| Contact resistance | ≤50Ω |
| Insulation resistance | ≥100Ω |
| Withstand voltage | ≥750VAC/1min |
| Switching life | ≥10000cycles |
Micro switch, micro switches, snap action micro switch, mini micro switch, push button micro switch
Outlook:
