KHL-250 High Speeed Wet Method Granulation Machine
In the cylinder (conical) container, powder materials and binder will be mixed into moist soft materials by the mixed paddles at the bottom. Then they will be cutted into uniform wet-particles by the side high-speed smashed paddles.
1.It is the structure of horizontal cylinder(cone).
2.Full sealed driving shaft, to use waterwhen cleaning.
3.Fluidization granulation, the finishedgranules are similar to roundness with good liquidity.
4.Compared with traditional process, it canreduce 25% binder and the dry time can be shortened.
5.Each batch of materials will be dry-mixedfor 2 minutes and be granulated for 1-4 minutes.
6.Compared with traditionalprocess, it has improved by 4-5 times.
7.All the processes of dry-mixing &wet-mixing & granulating are finished in a closed vessel.
8.So that it hasreduced the process and also complies with GMP standard.
9.Whole operation has the strict safetyprecautions.
Name |
Unit |
10 |
50 |
150 |
200 |
250 |
300 |
400 |
600 |
800 |
Volume |
L |
10 |
50 |
150 |
200 |
250 |
300 |
400 |
600 |
800 |
Output |
Kg/batch |
3 |
15 |
50 |
80 |
100 |
130 |
180 |
280 |
350 |
Mixing speed |
rpm |
300/600 |
260/400 |
240/360 |
180/270 |
180/270 |
140/220 |
106/155 |
80/120 |
80/120 |
Mixing Power |
kw |
1.5/2.2 |
4/5.5 |
6.5/8 |
9/11 |
9/11 |
13/16 |
18.5/22 |
22/30 |
26/34 |
Cutting Speed |
rpm |
1500/3000 |
||||||||
Cutting Speed |
kw |
0.85/1.1 |
1.3/1.8 |
2.4/3 |
4.5/5.5 |
4.5/5.5 |
4.5/5.5 |
6.5/8 |
9/11 |
9/11 |
1. we have seven technicians who gets passport ready to travel all over world to offer service to you.
2. We have 24hours hot line for Technical Support.
3. We get 18hours internet line for technical support.
4. Video camera in workshop to help you adjust and solve machine problem in working situation.
5. We have Technical Support in below Foreign Cities:
California (commission worker), Manila and Davao (Distributor), Lima (Agent), Ho Chi Ming and Hanoi (Agent), Dhaka (Agent), Lahore (Distributor)
